Forest-Master FM8 series Bedienungsanleitung Seite 3

12
11
10
1 Log Pusher (FM8)
2 Work Table
3 Wedge
4 Lifting Handle
5 Support leg
6 Log Retaining Plates
7 Push Button Switch
8 Motor
9 Push Button Box
10 Wheels (minor moving only)
11 Hydraulic Control Lever
12 Control Lever Guard
13 Bleed Screw
14 Oil Drain Bolt w/ Dipstick
15 Duocut Blade (FM10)
FM8(R/D/T) & FM10(R/D/T)
2
1
9 8
3
7 6
4
5
13
14
15
3
