Notices
Operating instructions
These operating instructions describe the safe and proper
handling of the product. All safety and general instructions
relating to the product and all local accident prevention
regulations and general safety instructions should strictly be
followed.
The drives should only be used for the opening
and closing of turning gates. The supplier is not
responsible for damage caused due to any other
use of the specifications in this manual.
Caution!
Installation and start-up only by persons after
technical instruction
Instruct all persons who use the gate system in its
proper and safe use.
Keep hand-held transmitters out of reach of
children.
Closely observe all opening and closing
movements of the gate when actuating the drive.
For safety reasons, no persons or objects are
permitted in the movement area of the gate.
Maintenance / inspection
The gate system should be inspected by a
specialist firm before the first start-up and as
needed but at last once every year.
Caution!
The closing force, if set too high, can cause injury
to persons or damage to assets.
Electrical connection
When making the cable connections, observe the
instructions in the manuals of components and
the wiring schematics.
Caution!
If the mains power cable of the device is
damaged or needs replacement, have a skilled
person who has received technical instructions do
this in order to avoid danger.
Specifications
Max. gate weight
Max. wing length
Min. wing length
Max. gate height
Door wing area
permeable
Supply voltage
Power consumption
Operating temperature
Thrust
Pull
Opening and closing time
Stroke
Duty cycle
Soft start / stop
Extern 24 VAC
General features
• The NovoSwing electromechanical drive has been developed
for swing wing doors of up to 1.8 meters wing width.
• Gates up to 1.8 meters wing width do not require an electric
lock. The lock position is maintained.
• Emergency release: For manual movement of the gate (in
case of power failure) with a key. The unlock mechanism is
easily accessible at the underside of the drive.
Install the control at a place from where you can see the gate.
Testing the gate system
Before starting installation work, check to make sure that the
drive can be used for the purpose for which you need it
considering the properties and dimensions of the gate (see
specifications).
• The right choice of the best-suited drive ensures proper
operation of the gate and reduces failure.
• (If installed properly) the drive complies with the applicable
safety requirements.
PRELIMINARY INSPECTIONS
Complete the following steps before defining the fulcrums:
• Define the point on the wing that is best for installation. If
possible, position the fulcrum at half wing height. If the gate
has no structural sectional bar, weld a holder to the point
suitable for the front fulcrum. This spreads the load on a wide
area.
• Before starting installation proper, make a thorough
inspection of the wings. Inspect the state of the wings and look
for cracks and damage.
Check to make sure that the wings are moving easily
• Check the hinges for ease of movement without play.
GB
200 kg
1.8 m
0.8 m
2.0 m
min 50% wind-
230 V + - 10 % 50 Hz
250 W
-20 °C / +60 °C
1500 N
1500 N
19 secs.
350 mm
30%
controlled
fuse 5x20 mm
3,15 AT
