1.7 Assembly Instructions
OPERATION
18
Transmission Assembly: To assemble the flexible
transmission to the motor, press the locking button
down completely, then the transmission coupling is
introduced into the coupling
of
the engine, making the
two planes
of
the terminal cable coincide with the
coupling lug, and introduce softly until the locking
button coincides with the safety housing
of
the
engine. If it drags DO NOT FORCE, make the engine
turn slightly to
ea se
the introduction and perfect
coupling. (See Fig.: 1.7-1)
Fig.: 1.7-1
Starting
of
the electric motor:
Before starting the electric motor, it will be checked that the network voltage coincides with the that
indicated on the characteristics plate, it will also be verified if the current collection is the same as that
of
the motor.
Starting
of
the petrol engines for the first use:
A) For measuring
of
security in the transport
of
shipment, aU the machines are given without
oil and without fuel in the motors.
B) Fuel: Filling the tank
of
fuel, all the petrol engine
of
the RABBIT Vibrator, it use gasoline for
automobile that is clean,
of 95
unleaded octanes.
C)
Oil: Filling the tank
of
oil
of
the motor, following the instructions
of
respective lubrication
of
the
maker
of
the motor that are attached to this manual.
With temperatures below 3°C., the vibrator may present difficulties to start after
a
long period
stopped, this is due to the solidifying
of
the grease bearings and
of
the shaft, it must start letting the
vibrator run light long enough for normal vibration to be achieved.
1.8 Use
of
Extension Cords
The extension cords are often required on jobsites to connect the motor. When choosing an
extension cord make sure it has adequate wire size for safety. An undersized cord will cause
a
drop
in line voltage resulting in a loss of power and overheating. In the Table
1.8-1
It shows the correct
wire size to use depending on cord length. If in doubt, use the next havier cord size.
On motors being used outdoors, use extension cords rated for outdoor use.
INGLÉS 1B-6
