1
B
OPERA TION
1.4 General Characteristics
The vibrator will be used by personnel trained for this job, it will only be used in specific jobs for which
it has been technically developed, after having read the instructions contained in this manual and
which must be fellowed correctly.
The manufacturer or authorised distributor must be consulted about any doubts.
Industrias Technof/ex S.A., will not accept any responsibility derived from incorrect installation,
manipulation, or misuse of the vibrator.
1.5 Safety at work
The RABBIT vibrator fulfils the E. C. regulation of safety at work, low voltage and vibration in portable
machines or hand driven, as well as ISO 6081 regulation, regarding noise at the place of work.
However the use of hearing protection during the vibrating time. The manufacturer will not accept
responsibilities for accidents if they derive from structure modification.
In addition to our recommendations the safety regulations of each country in force.
1.6 Conditions
of
Use
The vibrator RABBIT model, for concrete is designed to give maximum satisfaction to the user, as
long as the instructions of use and maintenance contained in this manual.
The RABBIT vibrator is designed to vibrate concrete and be used under the hardest conditions, both
environmental as well as use.
The Flexible Transmission is made up of
a
flexible rotating shaft and its cover.
The highly dimensioned Flexible Shaft, absorbs perfectly both the load applied as well as the high
number of turns.
The Flexible Cover protection of the shaft is of neoprene resistant to abrasion and tearing, with
intertwining braiding in steel tread and covered inside covered with
a
spiral steel strapping which the
flexible shaft slides down on.
The vibrating Needles is composed of an eccentric / wiper / lever wheel / tappet mounted on two
bearings pairs, special for high speed, situated on the inside of
a
metal tube of high resistence to
wearing, on the end of wich is
a
mounted point of steel specially hardened.
The vibrating needles musn't functioning in contact with solid and ridged prominent objects, for long
periods of time.
18-5
INGLÉS
