Please unfold page 5. Then you can always see
the operating elements and connections de-
scribed.
1 Individual Operating Elements
1 Locking screw for the joint of the wall bracket
2 Wall bracket
3 Transmitting antenna
4 Low-voltage inline jack for connecting the 12 V
operating voltage;
a low-voltage plug 5.5/2.5 mm (outside/inside
diameter) is required;
inner contact = positive pole
5 Sunshield
6 DIP switches for adjusting the transmission chan-
nel
7 Sealing rings
8 Housing cover

2 Safety Notes

The camera corresponds to all required directives of
the EU and is therefore marked with
Do not operate the camera in areas of extreme
temperatures (admissible ambient temperature
range -10 °C to +55 °C).
For cleaning the housing never use aggressive
detergents or chemicals.
No guarantee claims for the camera and no liability
for any resulting personal damage or material
damage will be accepted if the camera is used for
other purposes than originally intended, if it is not
correctly connected, operated, or not repaired in an
expert way.
If the camera is to be put out of operation
definitively, take it to a local recycling plant
for a disposal which is not harmful to the
environment.
3 Applications
In combination with a 2.4 GHz receiver of the
AV-... series from MONACOR and a monitor, the wire-
less cameras AV-3031COL (colour camera) and
AV-3031CCD (black-and-white camera) serve for wire-
less video surveillance. The transmission range large-
ly depends on the local conditions and the receiver
used. Without any obstacles between the camera and
the receiver, the maximum range may be 500 m. In
buildings, however, it is reduced to approx. 50 m by
walls and ceilings, depending on their condition. The
range can be increased several times over, however,
by using an antenna with gain on the receiver.
The camera is placed in a weatherproof housing
and is thus ideally suited for outdoor applications
(protection class of housing IP 65).
8
3.1 Conformity and Approval
Herewith, MONACOR INTERNATIONAL declare that
the wireless cameras AV-3031CCD and AV-3031COL
are in accordance with the basic requirements
and the other relevant regulations of the directive
1995/5/EC. The declaration of conformity can be
found in the Internet via the MONACOR INTER-
NATIONAL home page (www.monacor.com).
The wireless cameras are licence-free and
generally approved for operation in EU and EFTA
countries.

4 Operation

4.1 Adjusting the transmission channel
The wireless transmission is made in the 2.4 GHz
range which has been divided into five channels with
a distance of 14 MHz for this camera series. As a
maximum, three channels can be used simulta-
neously (channels 1, 3, and 5) as two adjacent chan-
nels will interfere with each other. If two channels are
required, several combinations are possible:
channel 1 with channel 3, 4, or 5
channel 2 with channel 4 or 5
.
channel 3 with channel 5
The camera is factory-set to channel 1 (2.4145 GHz).
If required, the channel adjustment can be modified.
For this purpose, remove the sunshield (5) first.
Caution: Do not tear off the antenna cable! Unscrew
the housing cover (8) on the rear side (four screws).
Carefully pull out the cover with the mounting slide
(fig. 2) without tearing off any leads. Adjust the chan-
nel on the transmitting module by means of the DIP
switches (6):
ON
1 2 3 4
Channel 1
When assembling, ensure a tight fit of all sealings to
make the housing weatherproof again. The two seal-
ing rings (7) will easily get lost.
4.2 Transmitting antenna
Screw the supplied omnidirectional antenna (3) into
the threaded jack of the weatherproof camera hous-
ing (see fig. 1).
IMPORTANT
For reasons of approval only use the supplied
antenna. If another antenna is connected, the ap-
proval will expire!
ON ON
1 2 3 4 1 2 3 4
Channel 2 Channel 3 Channel 4
ON ON
1 2 3 4 1 2 3 4
Channel 5
