I nd i c a t o r s o n L CD
SET TEMPERATURE
TIMER ON OFF
M O DE di s pl ay
Displays the current selected mode. Including AUTO,
COOL, DRY, HEAT (cooling & heating models only)
and FAN.
T r a n s m is s io n I nd i c a t or
This transmission indicator will light when remote
controller transmits signals to the indoor unit.
T e m p. /T i m e r dis p l ay
The temperature setting (from 17 C(62 F) to
30 C(88 F)) or timer setting (0~24h) will be displayed. O O
If FAN mode is selected, there will be no display.
O N /O F F dis p l ay
This indicator will be displayed when
the unit is operating.
M O DE di s pl ay (FAN mode)
FA N SPEED d i s play
Displays the selected fan speed: AUTO, HIGH,
and LOW. Nothing displays
selected in AUTO speed. When AUTO or DRY Mode
is selected, there will be no signals displayed.
RG51B19/(C)E-M model has no MED
NOTE:
FAN speed feature.
F O L L O W M E d is play
When pressing FOLLOW ME/TEMP SENSING button
in COOL or HEAT mode, the remote sensing function
is activated and this indicator displays.
T I ME R d i s p lay
This display area shows the settings of the TIMER.
That is, if only the Auto-on time function is set, it will
display TIMER ON. If only the Auto-off time function
is set, it will display TIMER OFF. If both functions are
set, it will display TIMER ON OFF which indicates you
have chosen both the Auto-on time and Auto-off time.
L O C K I n d icator
LOCK display is displayed when pushing the LOCK
button. Push the LOCK button to clear display.
6
O O
MED
when the fan speed is
