7-Channel Mode: All 16 LEDs as 1 segment
CH 1
0 - 15
16 – 23 R
24 – 31 G
32 – 39 B
40 – 47 W
48 – 55 RG
56 – 63 GB
64 – 71 BW
72 – 79 WR
80 – 87 GW
88 – 95 RB
96 – 103 RGB
104 – 111 GBW
112 – 119 RGW
120 – 127 RBW
128 – 135 RGBW
136 – 143 Dream
144 – 151 Meteor
152 – 159 Fade
160 – 167 Change
168 – 175 Flow 1
176 – 183 Flow 2
184 – 191 Flow 3
192 – 199 Flow 4
200 – 207 Flow 5
208 – 215 Flow 6
216 – 223 Flow 7
224 – 231 Flow 8
232 – 239 Flow 9
240 – 255 Sound
Note: When FLOW 8 or FLOW 9 under channel 1 is chosen, you can select the desired color under
channel 4 and 5 (0-255).
11-Channel Mode: Every 8 LEDs as 1 segment, 2 segments in total
CH 1 see CH 1 in the
7-Channel Mode
CH 2 see CH 2 in the
7-Channel Mode
CH 3 Flash
CH 4 R1
CH 5
G1
CH 6 B1
CH 7 W1
CH 8 R2
CH 9 G2
CH 10
B2
CH 11 W2
CH 2
Dimmer
(CH 1, 0 - 135)
Speed
(CH 1, 136 - 239)
Sensitivity
(CH 1, 240 - 255)
depending on the
setting of
channel 1
(0 - 255)
CH 3 CH 4
Red
(0 - 255)
Flash
(0 - 255)
Color select
Color select
27/32
CH 5 CH 6
Green Blue
(0 - 255) (0 - 255)
00063808.DOC, Version 1.0
CH 7
White
(0 - 255)
