Center of Gravity (CG)

The CG location is measured from the leading edge of the wing at the root.
This CG location has been determined with the recommended Li-Po battery
(EFLB22003S30) installed all the way forward in the battery compartment.

AS3X Control Direction Test

This test ensures that the AS3X
Assemble the aircraft and bind your transmitter to the receiver before
performing this test.
1. Raise the throttle just above 25%, then lower the throttle to activate AS3X.
CAUTION: Keep all body parts, hair and loose clothing away from a mov-
ing propeller, as these items could become entangled.
IMPORTANT: The AR636 programming for this aircraft increases control sur-
face movement when fl aps are fully down.
2. Move the entire aircraft as shown and ensure the control surfaces move in
the direction indicated in the graphic. If the control surfaces do not respond
as shown, do not fl y the aircraft. Refer to the receiver manual for more
information.
Once the AS3X system is active, control surfaces may move rapidly. This is
normal. AS3X remains active until the battery is disconnected.
10
® control system is functioning properly.
Aircraft
AS3X Reaction
movement
60mm
back from lead-
ing edge at
the root.
