AXIS Q3505-SVE Mk II Fixed Dome Network Camera
Video and Audio
To enable, go to Video & Audio > Camera Settings and select Enable View Areas.
To add a new view area:
1. Go to Video & Audio > View Area.
2. Click Add.
3. The new view area appears under Selected view area. Enter a descriptive name in the Name field.
4. Select an Aspect ratio and a Video stream resolution.
5. A new view area covers the whole image. Use the mouse to move and resize the view area.
6. Select Enable PTZ to enable digital PTZ for the view area.
7. Click Save to save the settings.
To modify a view area, select the view area in the list and modify the settings as required. Click Save.
To remove a view area, select the view area and click Remove.
Note
The PTZ functionality is useful during installation of the Axis product. Use a view area to crop out a specific part of the
full view.
Note
View areas will be disabled if Optical zoom for monitoring is selected. See PTZ Mode on page 10.

About overlays

Overlays are superimposed over the video stream. They are used to provide extra information during recordings, such as a timestamp,
or during product installation and configuration.
About overlay text
An overlay text can include the current date and time, or a text string. When using a text string, so-called modifiers can be used to
display, for example, the current bit rate or the current frame rate.
You can choose between the following text overlay sizes:
Size
Small
Medium
Large
It is also possible to display text when an action rule is triggered, see How to include overlay text in an action rule on page 26.
How to include overlay text
1. Go to Video & Audio > Video Stream and select the Image tab.
2. To include date and time, select Include date and Include time.
3. To include a text string, select Include text and enter the text in the field. Modifiers can be used, see File Naming &
Date/Time Formats in the online help
4. Select size, color, and placement of the text string.
Text height
10 pixels
16 pixels
21 pixels
.
25
Background height
20 pixels
28 pixels
36 pixels
