AXIS Q3505-SVE Mk II Fixed Dome Network Camera
Video and Audio
2. Select the new capture mode.
3. Click Save.
Note
When the capture mode is changed, the camera needs to reboot for the changes to take effect.
About scene profiles
A scene profile is a set of predefined image appearance settings including color level, brightness, sharpness, contrast and local
contrast. Scene profiles are preconfigured in the product for quick setup to a specific scenario, for example Forensic which is
optimized for surveillance conditions. For a description of each available setting, see the online help
You can still adjust the image appearance manually, see Image Appearance on page 22.
Image Appearance
To change Image Appearance go to the menus under Setup > Video & Audio > Camera Settings.
Increasing the Color level increases the color saturation. The value 100 produces maximum color saturation and the value 0
results in a black and white image.
The image Brightness can be adjusted in the range 0–100, where a higher value produces a brighter image.
Increasing the Sharpness can increase bandwidth usage. A sharper image might increase image noise especially in low light
conditions. A lower setting reduces image noise, but the whole image will appear less sharp.
The Contrast changes the relative difference between light and dark. It can be adjusted using the slidebar.
Local Contrast applies contrast to a specific area of the image. Use the slider to adjust the contrast, where a higher value produces
an image with high contrast between the dark and light areas and is suitable for scenes with wide dynamic range.
Image Correction
To change these settings go to Setup > Video & Audio > Camera Settings.
Electronic Image Stabilization (EIS)
When monitoring an environment that is subject to vibrations such as a train station, or when the camera is mounted on a pole,
images may appear unsteady. To automatically improve image stability, select Electronic image stabilization (EIS) from Video &
Audio > Camera Settings.
Barrel Distortion Correction
Barrel distortion is a lens effect that causes an image to look curved. The extent of distortion depends on the zoom level.
To edit barrel distortion settings, click Edit from Video & Audio > Camera Settings > Image Correction. In the Barrel Distortion
Correction window, adjust the slider to correct the distortion, using the grid for assistance.
Note
Barrel distortion correction also affects image width, height, and resolution. A higher level means that the image width
is retained at the expense of image height and resolution. A lower level means that image height and resolution are
retained at the expense of image width.
Enable Defog
Enable this feature from Video & Audio > Camera Settings to counter the effects of foggy weather and for a clear image.
Alternatively, click the Defog button in the product's Live View page. This button can be configured to appear in the Live View page
from Live View Config > Live View Layout. Use the Defog Effect slider to adjust the degree of correction as required.
