Technical Specifications; Package - CONDTROL NEO G220 Set Bedienungsanleitung

CROSS
CONDTROL NEO G220 Set
EN
LINE LASER
Control panel
3
1
1 Turn on/off laser lines in unlocked mode
2 Turn on/off:
- Pulse mode
- Laser lines in locked mode
3 Battery charge level indication
4 Locked pendulum indication
5 Pulse mode indication
8
user manual
4
5
2
CROSS
CONDTROL NEO G220 Set
EN
LINE LASER

TECHNICAL SPECIFICATIONS

Working range
Self-leveling accuracy
Self-leveling range
Operating temperature
Storage temperature
Tripod mounting thread
Laser type
Power supply
Dimensions
Weight

PACKAGE

Laser level NEO G220 – 1 pc.
Tripod 5/8'' – 1 pc.
Adapter 5/8'' – 1/4'' – 1 pc.
Cable tie – 1 pc.
Batteries (type AA) – 3 pcs.
User manual – 1 pc.
Hard case – 1 pc.
user manual
50 m
±0,3 mm/m
± 4,5°
0°C ... +50°C
-20°C ... +70°C
5/8'',1/4"
Green: class II 532 nm < 1 mW
Red: class II 630-670 nm < 1 mW
3 х 1.5V LR6 alkaline (AA)
120х75х105mm
0,5 kg
9
