LINE LASER

TECHNICAL SPECIFICATIONS

Working range
Self-leveling accuracy
Self-leveling range
Operating temperature
Storage temperature
Tripod mounting thread
Laser type
Power supply
Dimensions
Weight
* The operating range may differ from the declared depending on the
lighting conditions.

SET

Laser level - 1 pc.
Magnetic holder - 1 pc.
Adapter 5/8'' – 1/4'' - 1 pc.
Cable tie - 1 pc.
Power supply cable - 1 pc.
Pouch - 1 pc.
Batteries (AA) - 3 pcs.
User manual - 1 pc.
8
CONDTROL NEO G200
user manual
50 m*
±0,3 mm/m
± 4,5°
0°C ... +50°C
-20°C ... +70°C
5/8'', 1/4''
Class II 520 nm < 1 mW
3 х 1.5V LR6 alkaline (AA)
120х75х105mm
0,5 kg
CROSS
EN
LINE LASER

OPERATION

Before start operation remove the battery cover, insert the batteries,
observing correct polarity. Put battery cover back.
Use alkaline AA batteries only, all batteries should be of the same type
and brand with the same charge level. If battery charge level indicator
turns red while operation replace batteries or remove batteries from
the laser level and connect it to external power source using the power
supply cable included in the package. It is prohibited to connect laser
level to external power supply if alkaline batteries (AA) are installed.
Place an instrument on a firm and stable surface or a tripod.
Move compensator lock to choose necessary operating mode:
1) Automatic leveling, to build horizontal and vertical planes and
lines:
Move lever lock to unlocked position
If the product is out of the range of automatic compensation it will
emit sound signal.
Short press button to turn on necessary laser planes.
Short press button
working with laser receiver. In this mode pulse mode indicator will
turn green.
To switch off the product move lever lock to locked position
1) Locked compensator, to build inclined planes and lines:
Move lever lock to locked position
press button to turn on the product. Horizontal plane will
switch on. Locked pendulum indicator turns red.
Short press button
CONDTROL NEO G200
user manual
. Compensator is unlocked.
to turn on/off pulse mode that allows
. Compensator is locked. Short
to turn on necessary laser planes.
.
