3rd key press: Y flashes on the display.
You can now use the arrow keys to set the slope of
the Y axis in the same way as for the X axis.
4th key press: Confirms your input
After this, the device first starts levelling again, which
is shown by the flashing levelling display. After this,
the entered slope settings are approached.
During this procedure, the slope symbol blinks.
Once the values have been reached, the slope set-
tings and the slope symbol are displayed permanent-
ly lit.
If external influences change the position of the
device, the Autoslope monitoring system registers
this and automatically initiates adjustment. If the
device is tilted a relatively long way, the system
interrupts rotation and the laser beam and the
warning display flash rapidly.
If you press the slope key again, you can start
grading again, the device carries out levelling again
and approaches the stored slope settings again.
Important: The laser's mounting position and
possibly also the elevation and direction may,
however, have changed. This means that to be
on the safe side you should switch the device off
and back on again and adjust it.

4.2 Slope in Vertical Operation

In vertical operation too you can enter a grade. Of
course, you can only do this on the Y axis. To do
this, fix the laser in vertical position, start the laser
and press the X/Y key. Proceed as described in
point 4.
