11. Detector TE 90 ALIGN

11.1 Keyboard

Device symbol:
Laser connected
Battery display
Accuracy
Display
(on reverse too)
Centre notch
Button:
Short: Align On/Off
Long: LEDs On/Off
Menu: Arrow button up
Button:
Short: Accuracy
Long: Set reference
Menu: Arrow button
down
Battery compartment
(on reverse)
Numeric digits / text display
Arrow for direction of movement
Centre bar
Arrow for direction of movement
Display of audible signal
48
Magnet
LED: Direction of movement
Sensor window
LED for Centre
Fixing clamp
LED: Direction of movement
Bubble vial
Button On / Off
Button audible signal /
Menu: ENTER button
