Rotation speed

3.
The rotation speed can be regulated in four stages:
0, 200, 600, 800 and 1000 RPM. Pressing the rota-
tion key three times the laser stops (0 RPM). Each
time you press the key again, the rotation speed in-
creases.
At a standstill, you can move the laser dot using the
counterclockwise/clockwise rotation keys. Pressing
and holding down one of the keys speeds up the
movement of the laser dot.

Slope

4.

4.1 Slope in Horizontal operation

Alignment of the tripod head as to be as accurate as
possible, to guarantee an easier targeting and to use
the complete slope range of the laser of ±15% in
both axes.
The AUTOSLOPE function monitors the slope and
carries out adjustment automatically if necessary.
To do this, first use the sighting telescope or the
optical sight to align the laser exactly to the target
point and then enter the slope settings as follows:
1st key press: Slope is activated. The stored slope
settings of the last use are displayed and and the
automatically approached.
2nd key press: X, slope symbol and one digit flashes
on the display.
Use the arrow keys to set the slope. The blinking
digit can be changed.
To select the digits you must press the counter-
clockwise/clockwise rotation keys. For changing the
sign use the ± button. Plus is not displayed.
When you press and hold the arrow - keys the values
in the display will start to increase slowly and speed
up than.
Pressing both arrow keys at the same time resets the
respective display to 0.
