English
3. Layout & Connections
3.2 Connections
5V Connector:
USB 3.1 (Gen2) A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
USB 3.1 (Gen2) C-Port:
Note!
By dual assignment of the pins, the USB Type-C plug can be plugged into the port on both
sides.
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
ATTENTION!!!
Use only with Power Supply which is included in delivery!
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D- D+
Attention!
Never plug in with force
or in wrong direction.
10
EX-1240HMVS
