Contractor ECO-80P Bedienungsanleitung Seite 42

11 10
1 12
2
3
6
4
5
9 8
Picture 17. Special model ECO-80PL/ 100PL/ / 120PL/ 140PL
Pos. No Order code Description
Cartridge dust collector DC-550, incl. 0,55 kW fan,
17513
10 m² cartridge Àlter, pulse jet cleaning system
Cartridge dust collector DC-750, incl. 0,75 kW fan,
17514
15 m² cartridge Àlter, pulse jet cleaning system
1 15722 AirFlex-19, Compressed air hose 19x28mm, 1 m
2 15974 Diaphragm pulse-jet valve 3/ 4"
3 16106 Electronic timer for pulse-jet valve
4 15932 Pressure regulator, 1/ 4"
5 30404 Pressure gauge 1/ 8" (rubber cover)
6 15816 Pulse-jet cleaning manifold
42
7
A mount
0,5 m
1
1
1
1
1
CONTRACOR ® Version 2.3
