Pos. No Order code Description
Cabinet Enclosure ECO-80P , without cartridge dust collector
17205
and suction hose
Cabinet Enclosure ECO-100P, without cartridge dust collector
17206
and suction hose
Cabinet Enclosure ECO-120P , without cartridge dust collector
17207
and suction hose
Cabinet Enclosure ECO-140P, without cartridge dust collector
17208
and suction hose
Cartridge dust collector DC-370, incl. 0,37 kW fan, 8m²
17512
cartridge Àlter
1 17531 Plug 380 V
2 15904 Airline Filter 1/ 2", manual drain
3 15905 Pressure regulator 1/ 2", pilot operated
4 24407 Pressure gauge 1/ 4" (rubber cover)
5 15901 Air blow-off nozzle, rubber
6 15960 Rubber hose for air blow-off nozzle, 1m
7 12551
NTC-5.0, Short Venturi nozzle, tungsten carbide, 5.0x45 mm
8 12209 NHP-0, Nylon nozzle holder, for hose Ø13 x 27 mm
9 15720 ExtraBlast-13, Abrasive Blast Hoses 13x27, 1m
10 15606 RGS-600, Rubber blast cabinet gloves, pair
11 17529 Hand hole rubber
12 17530 Hand hole ring
13 16049 Gasket 3х15, Disposable window / Electrical enclosure, 1m
14 16077 Disposable window for ECO-series, 500 х 320 mm
15 16076 Safety glas window, 476 х 296 mm
16 16064 Rubber proÀle, 1m
17 16064 Rubber proÀle, 1m
18 16078 Light glas window, 646 х 186 mm
19 17534 Handle
17552 Gas spring, ECO-80
17537 Gas spring, ECO-100
20
17553 Gas spring, ECO-120
17554 Gas spring, ECO-140
21 17533 Socket 230V
22 17532 Socket 380V
23 15931 Pneumatic foot pedal
24 16026 Pneumatic Àtting M5 x 6 mm
25 15985 Ventilation hose Ø 150mm, 1m
26 15985 Ventilation hose Ø 150mm, 1m
CONTRACOR ® ECO-series pressure blast cabinets
A mount
1
1
1
1
1
2 m
1
1
3 m
1
4
2
2 m
1
1
1
1
1
2
2
2
2
2
1
1
1
2
2 m
0,2 m
