Contractor ECO-80P Bedienungsanleitung Seite 40

27 17518 Dust container, 10 liter
28 17542 Gasket, Cabinet door ECO / Dust collector DC-370, 1m
29 17542 Gasket, Cabinet door ECO / Dust collector DC-370, 1m
30 15739 Impeller for DC-370
31 15968 Filter cartridge 8 m², for DC-370
32 16217 Washer M8, large
33 16207 Wing nut M8
34 17535 Electric motor 0,37 kW
35 15975 Rubber air hose, brown, 1m
36 15990 Pneumatic tube 6x4 mm, 1m
37 15918 Filter element 5 µm, Cellpor
38 10520 FSV-0, Abrasive metering valve 1/ 2"
39 17536 Blast machine assembly, 13 liter, for ECO-series
40 17538 Blow-out valve, ECO-series
21 10903 CFT-0, Sandblast coupling 1/ 2"
42 12309 CQP-0, Nylon hose coupling, for hose Ø13 x 27mm
43 16037 Dust collector latch
44 15926 Pneumatic Àltration and control unit 1/ 2"
45 15928 PC container with semi-automatic condensate drain
46 16390 Rubber gland, Air blow-off nozzle, for all ECO/ CAB
47 16395 Rubber plug
48 16392 Rubber gland, Abrasive blast hose ExtraBlast-13, for all ECO-P
17556 Floor plate, left for ECO-80
17558 Floor plate, left for ECO-100
49
17560 Floor plate, left for ECO-120
17562 Floor plate, left for ECO-140
17557 Floor plate, right for ECO-80
17559 Floor plate, right for ECO-100
50
17561 Floor plate, right for ECO-120
17563 Floor plate, right for ECO-140
40
1
6 m
2 m
1
1
1
1
1
3 m
3 m
1
1
1
1
1
1
4
1
1
2
2
2
1
1
1
1
1
1
1
1
CONTRACOR ® Version 2.3
