GB
Wireless weather station

Specifications:

radio controlled clock
indoor temperature: -10 °C to +50 °C
outdoor temperature: -40 °C to +60 °C
temperature resolution: 0.1 °C
temperature measurement accuracy: ±1 °C (20 to 24 °C), otherwise ±2 °C
wireless sensor: transmission frequency 433 MHz
radio signal range: up to 35 m in an open area
number of sensors per connection: max. 3
indoor and outdoor relative humidity: 20 % to 95 %
resolution: 1 %
measurement accuracy: ±5 % (30 to 80 %), otherwise ±8 %
bar. pressure measurement range: 800 hPa to 1 100 hPa
power supply:
main unit: 2× 1.5 V AAA batteries (not supplied)
sensor: 2× 1.5 V AA batteries (not supplied)
dimensions and weight without batteries:
main unit: 110 × 110 × 47 mm, 125 g
sensor: 91 × 60 × 28 mm, 39 g

Display Description

2 3
1
16
15
14
13
12
1. Indoor temperature
2. Weather forecast icon
3. MAX/MIN measured values
4. Outdoor temperature
5. Pressure trend
6. Outdoor humidity
Back
1
4
1. Speaker
2. Weather station control buttons (MODE, UP/CH,
DOWN/CF/WAVE, MEM/HPA, AL ON/OFF, SNZ/LIGHT)

Getting Started

First insert batteries into the main unit, then into the wireless sensor. Do not combine old and new or various kinds of batteries
(alkaline, carbon-zinc and nickel-cadmium); do not use rechargeable batteries!
4
5
6
7
8
9
10
11
7. Signal reception from sensor icon
8. Glaze ice icon
9. Sensor number
10. Alarm icon
11. Current time
12. DCF signal reception icon
2
3
3. Stand
4. Battery compartment
2
13. DST icon
14. Date/pressure
15. Sensor battery flat icon
16. Indoor humidity
