Massoth eMOTION XLS Konfigurationsanleitung Seite 43

CV-Table (Sound settings)
This table shows the sound decoder settings (S= Standard, A = Analog operation)
Table of configuration variables
CV Description
131 Add. sound 1 : Switching command
132 Add. sound 2 : Switching command
133 Add. sound 3 : Switching command
134 Add. sound 4 : Switching command
135 Add. sound 5 : Switching command
136 Add. sound 6 : Switching command
137 Add. sound 7 : Switching command
138 Add. sound 8 : Switching command
139 Add. sound 9 : Switching command
140 Add. sound 10 : Switching command
141 Add. sound 11 : Switching command
142 Add. sound 12 : Switching command
147 Amplifier On/Off : Switch. command
Start up/shut down (Diesel-/Electric)
148
resp. cylinder sound (Steam engine)
149 MASSOTH Sound Configuration
Bit Wert
Bit 0 1
Bit 1 2
Bit 2 4
Bit 3 8
Bit 4 16
Bit 5 32
Bit 6 64
150 Starting Inhibit between startingphase
AUS (Wert 0)
Random Generator OFF
Standing Noise OFF
Standard driving sound
Cylinder valves closed
Contacts standard
Automatic side noises OFF
Start signal delay OFF
A Range Note
0...16 0=deactivated, sound can not
*
be triggered by F-key
* 0...16
1...16 = F-key assignment:
* 0...16
sound will be triggered by the
* 0...16
respective F-key
* 0...16
Note: Only one sound may
be programmed to an F-key.
* 0...16
In case multiple sounds are
* 0...16
assigned to one F-key only the
* 0...16
first sound programmed will
* 0...16
be triggered.
* 0...16
* 0...16
* 0...16
6 0...16 0 = Light
1...16 = Function Key
5 0...16
4 √ bitwise programming
AN
Random Generator ON
Standing Noise ON
load-dependant sound
Cylinder valves open
Contacts direction sensitive
Automatic side noises ON
Start signal delay ON (CV 7)
0 = off, 1 = digital, 2 = analog,
0 0... 3
3 = digital + analog
