Control Standard Factory Settings - Emerson Liebert XDK-W Handbuch

CoolTherm
Manual / Bedienungsanleitung
40 kW
35 kW
30 kW
25 kW
20 kW
15 kW
10 kW
5 kW
0 kW
10,0 °C 12,0 °C

10.5 Control Standard Factory Settings

start of fan rotation
fan speed control
start of 3-way valve
control of 3way valve
front LED yellow
front LED red
automatic door opening
Note:
CoolTherm
25kW-CoolTherm at 3.58m³/h chilled water flow rate
14,0 °C 16,0 °C
chilled water supply temperature [°C]
10°C (start with 75% rotation)
20 – 23°C (75% - 100% rotation)
10°C (start with closed position)
16 – 19°C (0 – 100% control water flow rate)
temperature alarm >26°C or rear door open
temperature alarm >26°C and rear door open
door release at 35°C
All settings could vary by project.
01_998_330_0_k
20°C supply air temperature 1)
22°C supply air temperature 1)
25°C supply air temperature 1)
18,0 °C 20,0 °C 22,0 °C 24,0 °C
(option)
(option)
(option)
page / Seite 48/98
