GETTInG STArTED

Installing the Cutting Blade Assembly

the Cricut Expression 2 cutting blade assembly is located in the bottom of your box,
separate from the machine. Before you turn the machine on, you will need to insert the
blade assembly. to do this:
1. open the front door on the Cricut
Expression 2 machine. Remove the
cardboard inserts from both sides of
the carriage.
2. Remove the cutting blade assembly from
its bag. the blade assembly fits into
the black cradle on the left side of the
carriage. Rotate the adjustment knob on
the top of the blade assembly so that the
black arrow on the blade assembly points
to the number 3 on the adjustment knob.
3. Locate the silver nut and turn it
counterclockwise until it loosens enough
that you can swing the screw to the right.
Be careful not to loosen the screw too
much or it will fall out.
4. open the left arm of the black cradle and
position the cutting blade assembly inside
as shown with the black arrow facing you.
Ensure that the cutting blade has been
inserted into the assembly with the sharp
blade end pointing down. Close the cradle,
swing the nut back to the left, and tighten
it by turning it clockwise.
6 GEttING StARtED
