Residual Risks

In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:
– Impairment of hearing.
– Risk of personal injury due to flying particles.
– Risk of burns due to accessories becoming hot
during operation.
– Risk of personal injury due to prolonged use.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
DATE CODE POSITION
The date code, which also includes the year of
manufacture, is printed into the housing.
Example:
2015 XX XX
Year of Manufacture

Package Contents

The package contains:
1 Collated magazine attachment
1 PR2 collated screwdriver bit (DT7205-QZ)
1 Instruction manual
• Check for damage to the attachment, parts or
accessories which may have occurred
during transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (fi g. 1)
WARNING: Never modify the
attachment or any part of it. Damage or
personal injury could result.
a. Screw guide
b. Screw length adjustment
c. Fine depth adjustment
d. Advancing mechanism
e. Shoe
f. Advancing mechanism removal button
g. Release buttons
h. Collated screwdriver bit
INTENDED USE
This collated drywall magazine is a professional
attachment designed to be used with the DCF620
or DCF621 D WALT screwdriver for professional
E
driving of collated screws.
DO NOT use under wet conditions or in the
presence of flammable liquids or gases.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• Young children and the infirm. This appliance
is not intended for use by young children or
infirm persons without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.

ASSEMBLY AND ADJUSTMENTS

WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.
WARNING: Use only D
packs and chargers.
Fitting the Collated Screwdriver Bit
(fi g. 1 & 2)
NOTICE: For proper operation only use
a D WALT collated screwdriver bit.
E
1. Remove the nose cone from the screwdriver.
2. Remove the mounted bit and bit holder from
the screw driver.
NOTE: Refer to and follow all instructions on
changing bits and holders in your screw driver
manual.
3. Insert the provided collated screwdriving bit (h)
into the bit holder until it clicks into place.
ENGLISH
WALT battery
E
15
