BlaDe spInDle assemBly - 3452/61
22
21
23
9
14
15
16
17
Item
Order
Description
No.
No.
1
623762
Blade Spindle Assembly Rt
(includes items 3-19)
2
623763
Blade Spindle Assembly Ctr/Lt
(includes items 3-10, 13-20)
3
243331
Bolt .375-24 x 1
4
257041
Cupped Washer .375 x 1.562
5
721167
Top Bearing Shield
6
110082
Bearing 25mm - Single Seal
7
604421
Spindle Housing w/Studs
(includes item 9)
8
280745
Grease Fitting .25-28 x 1.125
9
247141
Stud Bolt .312-18 x 1.25
10
903643
Spacer – Bearing
04-03083B / 04-03084B
Rev. 08-05
3
4
5
19
7
8
10
6
20
18
13
03083B
CENTER / LEFT
22
21
23
9
2
14
15
16
17
RIGHT
Item
Order
No.
No.
11
604774
12
282630
13
423680
14
421200
15
257061
16
257432
17
243581
18
772061
19
110080
20
604775
21*
415892
22*
281580
23*
253035
*Not included with assemblies
39
3
4
12
5
19
7
8
10
1
6
11
18
13
03084B
Description
Spindle Shaft Assembly 6.5
Spacer .75
Deflector Cone
Fiber Washer
Flat Washer
Lock Washer .5
Bolt .5-20 x 2
Washer .510 x 2.625
Bearing 25mm - Double Seal
Spindle Shaft Assembly 5.75
Sheave 6.0
Square Key .25 x .690
Whiz Nut .312-18
