Item Order Description
No. No.
1 644461 Lift Channel Rt.
644462 Lift Channel Lt.
2 824982 Fork Housing
(includes item 3)
3 123522 Bearing Cup
4 122522 Tapered Bearing
5 257091 Washer .75 x 14 Ga.
6 253992 Lock Nut .75-16
7 481434 Dust Cap
8 282615 Spacer .375 x 1.031 x 1.5
9 125855 Seal
10 644221 Fork
11 603973 Wheel Assembly
Wheel lIFt assemBly
20
03082
18
1
20
20
16
11
12
13
Item Order
No. No.
12 902428
13 120048
14 247715
15 253970
16 822312
17 424053
18 243609
19 243614
20 253930
38
7
19
19
17
20
13
10
14
Description
(includes items 12 & 13)
Spacer - Axle
Bearing
Carriage Bolt .625-11 x 5.625
Lock Nut .625-11
Stabilizer w/Bumper
(includes item 17)
Rubber Bumper
Bolt .5-13 x 3.312 Grade 5
Bolt .5-13 x 3.562 Grade 5
Lock Nut .5-13
6
5
4
3
18
2
3
4
8
9
15
03082
