ROLLER SHUTTER TRANSMITTER
23
26 25 U
(20) Roller shutter transmitter
20
(21) Status LED roller shutter transmitter
(22) Learn button on roller shutter transmitter
(23) Selection jumper 'AND/OR'
21
(24) Battery CR2477
(25) Magnet
(26) Roller shutter transmitter
22
(U) Packer parts
24
Open the casing by lifting the
side with a screwdriver
+
Battery
CR 2477
Casing cover
Magnet
Screws
Lower casing
Packer parts
(optional)
