WINDOW TRANSMITTER
12
Open the casing by lifting the
side with a screwdriver
9
10
11
13
+
Battery
CR 2477
Transmitter
Window casement
Window frame
(9) Window transmitter
(10) Status LED on window transmitter
(11) Learn button on window transmitter
(12) Select jumper 'AND/OR'
(13) Battery CR2477
(14) Magnet
(U) Packer parts
14 U
Magnet
Washers
EN
Casing cover
Magnet
Screws
Lower casing
Packer parts
(optional)
