Protector AS-7000 Betriebsanleitung Seite 24

EN
THERMO TRANSMITTER
15
(15) Thermo transmitter
(16) Status LED thermo transmitter
(17) Learn button thermo transmitter
(18) Connection thermo transmitter
(19) Battery compartment 3 x AA
T = Thermo transmitter
(a) 3 mm holes for support brackets
(b) 4 mm holes for thermo transmitter
24
19
a
16
17
18
(Figure 3)
T
b
