Technical Data

Inputs ............................................................................... 4 x RCA / Cinch
Input sensitivity ................................................................ RCA / Cinch 2 - 4 Volts
Outputs ............................................................................ 6 x RCA / Cinch
Output voltage .................................................................4 Volts
Frequency response ........................................................10 Hz - 44,000 Hz
DSP resolution .................................................................64 Bit
DSP power ......................................................................295 MHz (1.2 billion MAC operations/second)
Sampling rate ..................................................................96 kHz
DSP type .........................................................................Audio signal processor
Signal converters ............................................................. A/D: Asahi Kasei
Signal-to-noise ratio digital input .....................................106 dB (A-weighted)
Signal-to-noise ratio analog input ....................................103 dB (A-weighted)
Total harmonic distortion (THD+N) digital input ...............< 0.001 %
Total harmonic distortion (THD+N) analog input .............< 0.002 %
IM distortion (IMD) digital input ........................................< 0.004 %
IM distortion (IMD) analog input ......................................< 0.004 %
Crosstalk..........................................................................> 90 dB
Operating voltage ............................................................9.6 - 18 Volts (max. 5 sec. down to 6 Volts)
Current draw ....................................................................< 400 mA
Max. remote output current .............................................500 mA
Additional features ...........................................................HEC slot, Ground lift switch, Control Input, 32 Bit
Dimensions (H x W x D) ..................................................40 x 177 x 104 mm / 1.58 x 6.97 x 4.09"

Warranty Disclaimer

The limited warranty comply with legal regulations.
Failures or damages caused by overload or im-
proper use are not covered by the warranty. Please
return the defective product only with a valid proof
of purchase and a detailed malfunction description.
Technical specifications are subject to change!
Note: "The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
®
Audiotec Fischer GmbH is under license. Other trademarks and trade names are those of their respective owners."
E-mail: helix@audiotec-fischer.com · Internet: www.audiotec-fischer.com
Audiotec Fischer GmbH
Hünegräben 26 · 57392 Schmallenberg · Germany
Tel.: +49 2972 9788 0 · Fax: +49 2972 9788 88
4 x Highlevel speaker input
1 x Optical SPDIF (12 - 96 kHz)
1 x Remote In
Highlevel 5 - 11 Volts
1 x Remote Out
D/A: Asahi Kasei
CoProcessor, ADEP.3 circuit, Auto Remote switch
Errors are reserved! For damages on the vehicle
and the device, caused by handling errors of the
device, we can't assume liability. This product is
tagged with a CE-Certifikation mark. Thereby these
devices are certified for the use in vehicles within
the European Community (EC).
