Technical Data

Inputs ...............................................................................6 x RCA / Cinch
Input sensitivity ................................................................RCA / Cinch 2 - 4 Volts
Outputs ............................................................................8 x RCA / Cinch
Output voltage .................................................................6 Volts
Frequency response ........................................................10 Hz - 22,000 Hz
DSP resolution .................................................................64 Bit
DSP power ......................................................................295 MHz (1.2 billion MAC operations/second)
Sampling rate ..................................................................48 kHz
DSP type .........................................................................Audio signal processor
Signal converters .............................................................A/D: BurrBrown
Signal-to-noise ratio digital input .....................................112 dB (A-weighted)
Signal-to-noise ratio analog input ....................................107 dB (A-weighted)
Total harmonic distortion (THD+N) digital input ...............< 0.0008 %
Total harmonic distortion (THD+N) analog input .............< 0.002 %
IM distortion (IMD) digital input ........................................< 0.003 %
IM distortion (IMD) analog input ......................................< 0.005 %
Crosstalk..........................................................................> 90 dB
Operating voltage ............................................................9.6 - 18 Volts (max. 5 sec. down to 6 Volts)
Current draw ....................................................................< 480 mA
Max. remote output current .............................................500 mA
Additional features ...........................................................HEC slot, Ground lift switch, Control Input,
Dimensions (H x W x D) ..................................................40 x 177 x 120 mm / 1.58 x 6.97 x 4.72"

Warranty Disclaimer

The limited warranty comply with legal regulations.
Failures or damages caused by overload or im-
proper use are not covered by the warranty. Please
return the defective product only with a valid proof
of purchase and a detailed malfunction description.
Technical specifications are subject to change!
Note:
"The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
®
Audiotec Fischer GmbH is under license. Other trademarks and trade names are those of their respective owners."
6 x Highlevel speaker input
1 x Optical SPDIF (12 - 96 kHz)
1 x Remote In
Highlevel 3.5 - 11 Volts
1 x Remote Out
D/A: BurrBrown
ADEP circuit, Auto Remote switch
Errors are reserved! For damages on the vehicle
and the device, caused by handling errors of the
device, we can't assume liability. This product is
tagged with a CE-Certifikation mark. Thereby these
devices are certified for the use in vehicles within
the European Community (EC).
