remote output of the DSP to activate connected
amplifiers!
8 Ground lift switch
The ground of the HELIX DSP MINI signal in-
puts is galvanically decoupled from the ground of
the signal outputs. In many cars this setup is the
best way to avoid alternator noise. Nevertheless,
there are use cases where it will be necessary to
directly connect input and output ground or to tie
both grounds together via a resistor. Therefore the
Ground lift switch has three positions:
-
center position:
input
separated.
-
left position: input and output ground tied
together.
-
right position:
input
connected via 200 Ohms resistor.
9 Control pushbutton
The DSP MINI provides 10 internal memory loca-
tions for sound setups. The Control pushbutton
allows the user to switch between two memory po-
sitions. These can be defined in the DSP PC-Tool.
Note: The memory locations one and two are de-
fined ex works.
To manually switch between the setups the button
has to be pressed and held for one second. Switch-
ing is indicated by a single red flash of the Status
LED. To switch between all internal memory loca-
tions, the optionally available DIRECTOR display
remote control is recommended.
Pressing the button for five seconds completely
eras es the internal memory. This is indicated by a
continuous red glowing and constant green flashing
of the Status LED.
Attention: After erasing the setups from memory
the HELIX DSP MINI will not reproduce any audio
output.
Status LED
10
The Status LED indicates the operating mode of the
signal processor and of its memory.
Green: DSP is ready for operation.
Orange: Power Save Mode is active.
Red: Protection Mode is active. This may have
different root causes. The HELIX DSP MINI is
equipped with protection circuits against over- and
undervoltage as well as overheating. Please check
and
output
ground
and
output
ground
for connecting failures such as short-circuits or oth-
er wrong connections.
If the DSP is overheated the internal temperature
protection switches off the remote and signal output
until it reaches a safe temperature level again.
Red / green slow flashing: No operating software
installed. Connect the signal processor to the
DSP PC-Tool software and confirm the automat-
ic update of the operating system. You will find
the latest version of the DSP PC-Tool software at
www.audiotec-fischer.com.
Red / green fast flashing: The currently selected
Sound Setup memory is empty. A new setup has to
be loaded via the DSP PC-Tool software or switch
to a memory position with existing sound setup.
USB input
11
Connect your personal computer to the DSP MINI
using the provided USB cable. The required PC
software to configure this signal processor can be
downloaded from the Audiotec Fischer website
www.audiotec-fischer.com.
Please note: It is not possible to connect any USB
storage devices.
Control Input
12
This multi-functional input is designed for HELIX
DSP MINI accessory products like a remote control
which allows to adjust several features of the signal
processor. Depending on the type of remote con-
trol, at first its functionality has to be defined in the
" Device Configuration Menu" of the DSP PC-Tool
software.
Line Output
13
6-channel pre-amplifier output for connecting po wer
amplifiers. The output voltage is 4 Volts max. Please
make sure that you always turn on / off external am-
plifiers using the remote output of the signal proces-
sors Power Input. Never directly control the external
amps by a signal from the ignition switch of your
car! Additionally this output will be turned off when
the "Power Save Mode" of the signal processor is
active. The outputs can be assigned to any of the
inputs as desired using the DSP PC-Tool software.
17
