These operating and assembly instructions must be avail-
able to all personnel operating, maintaining and cleaning the
appliance. Read these Operating and Assembly Instructions
carefully before installing and putting the blower into service.
Subject to change. If in any doubt, the manufacturer should
be consulted. This document is protected by copyright. It
must not be disclosed to third parties without our express
written consent. Any form of duplication or recording and
storage in electronic equipment is forbidden.
1 MACHINE SPECIFICATIONS
Please refer to the cover sheet for our address.
For details of the scope of these Operating and Assembly
Instructions, please refer to the Declaration of Installation
Conformity pursuant to Annex II 1 B.
The technical data on page 20 apply to the standard version.
Your blower's specifi cations may differ from these specifi ca-
tions (refer to rating plate). If this is the case, please refer to
the enclosed, additionally applicable documents or your own
applicable Operating and Assembly Instructions.
10
Rating Plate
The data on the rating plate is applicable to connection,
maintenance and ordering of spare parts. Also refer to the
rating plate for the serial number of the appliance and its year
of manufacture.
Typ
Mot. EN 60034-1
kW cos
Hz
1.1 Designated use
Elektror conveyor blowers have impellers made of welded
steel sheet metal. Their blades terminate radially.
The conveyor blowers are suitable to convey plastic granu-
late, recycled plastic as well as light bulk goods of all kinds.
Substances or mixtures of substances that may cause spe-
cial hazards during operation must not be conveyed, e.g.
combustible dusts, explosive substances, substances that
are chemically unstable or substances that may react with
D-73760 Ostfildern
Germany
Nr.
IP W-Kl.F
kW cos
min -1 min -1 Hz
V
A A
each other. The blowers are not suitable to convey or to be
used in a potentially explosive atmosphere.
Use of the blowers for
• aggressive,
• abrasive,
• sticky,
• toxic,
• potentially explosive or
• very moist
media is not permissible.
For the standard version the temperature of the conveyed
media must not be below -20°C and not exceed +60°C.
The blower is not suitable for installation outdoors without
special measures. The blower is fundamentally designed for
S1 operation (continuous operation). However, a maximum
of 30 switching operations per hour are permitted.
Special versions for applications not mentioned above are
available on request. Remodelling and modifi cation of the
blower are not permitted. In the case of special equipment,
the enclosed supplementary Operating and Assembly In-
structions must be observed and adhered to. The supple-
mentary instructions differ in certain respects from these Op-
erating and Assembly Instructions.
Elektror conveyor blowers offer a high level of operational re-
liability. As the conveyor blowers are high powered machines
the following instructions must be strictly observed in order
to avoid injuries, damage to objects and the machine itself.
1.2 Mechanical hazards
The mechanical hazards in Elektror blowers have been mini-
mised in accordance with the current state of the art, as well
as the requirements for safety and health protection. To elimi-
nate any further risk on the part of the operator, we recom-
mend that suitable protective gear be used and worn during
all lifecycle phases of the appliance (please refer to the in-
structions below).
1.3 Hazards arising from reaching in and unexpected
start-up
The rotating parts inside the appliance pose a high risk of
injury during operation. Before opening, reaching in or insert-
ing tools into the appliance, always shut it down and wait
until all moving parts come to a standstill. Make sure the ap-
pliance is reliably protected against restarting while work is
in progress.
Make sure that during the entire time period no medium or
e.g. a mixture of medium and air can enter the blower.
Also make sure that no hazardous situation can occur as a
consequence of restarting after shutdown, e.g. as a result of
a power cut or blockage.
To avoid injuries during operation by reaching in or by eject-
ed media, all hoses or pipes must have a fi xed connection at
both the suction and discharge ports.
1.4 Weight and stability
Beware of falling hazards during transportation and installa-
tion in particular. Refer to 2.1 - Transportation and handling,
V
as well as 3.1 - Installation and assembly.
1.5 Suction effect
The blowers produce a powerful suction effect.
Warning!
Objects, items of clothing and also hair can be
sucked into the intake port. Risk of injury!
(danger of injury from impeller!).
Warning!
Do not stand near the intake opening during
operation. If the blower is operated without a con-
