1. Press the Read button again to display the
7.
area unit on the bottom line of the screen;
the width is simultaneously displayed on the second
line (fig. 10).
8.
2. Press the Read button to conduct a new measure-
ment.

Volume measurement

1. Press the Mode button (4) to select the volu-
me measurement mode. The flashing line in the
symbol indicates the length to be measured (fig.
11).
2. Press the Read button to activate the laser; the
laser indicator will now flash from top to bottom.
3. Position the device in such a way that the laser is
aimed at the point to be measured.
4. Press the Read button to display the measured
length on the first line of the screen. The line for
the width in the
12).
5. Position the device in such a way that the laser is
aimed at the point to be measured.
6. Press the Read button again to display the width
on the second line of the screen. The line for the
height in the
7. Press the Read button again to display the volu-
me on the bottom line of the screen; the height is
simultaneously displayed on the third line (fig. 14).
8. Press the Read button to conduct a new measure-
ment.
symbol will start to flash (fig.
symbol will start to flash (fig. 13).
84
Fig. 10
Fig. 11
Fig. 12
Fig. 13
Fig. 14
