14
Your shock is set up correctly if it compresses not more
than 30% when you sit on the bike (SAG). Propain's
recommendation is 25% for this bike.
Ask a friend for help to find the right air pressure or the right steel
spring. He can either measure the remaining visible length of the
piston rod or read the number of the SAG indicator that is visible on
most of the recent air shock's pistons.
To adjust the SAG, please change the air pressure. Before meas-
uring the SAG again compress the shock several times to make
sure the pressure has distributed into all air chambers inside the
shock.
When using a coil shock, you can find your right spring in the table
below.
Rider weight (with all gear)
57kg / 125lbs
64kg / 141lbs
72kg / 158lbs
80kg / 176lbs
88kg / 194lbs
97kg / 213lbs
i
Recommended spring
350 lbs/inch
400 lbs/inch
450 lbs/inch
500 lbs/inch
550 lbs/inch
600 lbs/inch
In addition to the according SAG adjustments, the compression
speed has to be dampened to avoid a "bottom out". To adjust this
setting turn the screw or lever on your damper saying "compression"
or "high speed compression". If you experience "bottom out" with
your setting increase the compression damping.
"Bottoming out" your suspension can lead to damage of the frame,
parts and / or the shock.
If you are uncertain in any of the points mentioned above, please
do not hesitate contacting Propain or your local bike dealer.

Fork

Forks with up to 203mm of travel are approved to be used with the
Rage. A fork length of more than 588mm must not be used as it
leads to forces on the frame for which it was not approved. The fork
length is measured from the middle of the front axle to the top of the
lower fork crown.
In the worst case scenario, the use of a too long fork
could result in a crack or damage of the frame while
riding the bike. This could cause a crash and / or severe
