Instruction CF-RS Standard Room Thermostat

3. Transmission Test

Initiate transmission test on
Room Thermostat - fig. 1
• Press the push button
• LED
Link test is satisfactory
• LED
Link test is unsatisfactory
• LED
No Link connection to Room Thermostat
• Try to relocate Room Thermostat in the room
• Or install Repeater Unit (CF-RU) and locate be-
tween Master Controller and Room Thermostat
Note: Master Controller output LED(s)
room thermostat, flash(es) during Link test

4. Mounting

Placing the Room Thermostat - fig. 5
! Wherever possible, the room thermostat should be
installed at a place where the effect of sunlight,
draught, other heaters (eg. TV's), etc. is avoided
VI.UH.L4.1C
6
goes ON
goes OFF
flashes 5 times
Produced by Danfoss Floor Heating Hydronics 03.2007
connected to the
.
