Instruction CF-RS Standard Room Thermostat

1. Functional Overview

Front - fig. 1
Turning knob & push button
Red LED (behind the cover)
LED modes
• Permanent light
• No light
• Slow flashing
• Fast flashing
Back - fig. 2
Back plate
Turning knob release
Back plate lock/unlock (turn 90°)
Screw hole for wall mounting
Battery placement
Screw and wall plug
Note: To activate batteries please remove enclosed strips
from batteries
Turning Knob - fig. 3
Turning knob release
Room temperature limitation - fig. 4
Minimum limitation (blue) (from 0°C)
Maximum limitation (red) (up to 30°C)
VI.UH.L4.1C
4
ON
OFF
Flashes
Flickers
