Status display / Error codes

The symbols in the table below show the meter's operational status.
The status messages only appear in the main display (energy). The
temporary display of the warning triangle can be caused by special
Symbol Status
Attention!
Data transmission
Symbol constantly displayer:
Emergency operation
Code Error
1 Short-circuit return sensor
2 Interruption return sensor
3 Short-circuit supply sensor
4 Interruption supply sensor
5 Hardware error
Battery empty or wrong temp.
6
Sensor
Temperatures out of measuring
7
range
100 Emergency operation
1000
2000
> 8000 Internal hardware error
Error codes show faults detected by multidata. If more than one error
1000 and error 5.
Measure
-
-
-
-
Measure
Check sensors, replace if needed
Check sensors, replace if needed
Check sensors, replace if needed
Check sensors, replace if needed
Correction heating system
-
25
