Inhaltszusammenfassung für QED MusiQ RFS System

  • Seite 2: Declaration Of Conformity

    If the cable shows any sign of wear or damage, immediately stop using it and obtain a proper replacement from a qualified service agency or from the QED service department. If the MusiQ shows signs of improper operation, or if it has been dropped or damaged in any way, immediately disconnect the power cord from the wall.
  • Seite 3: Inhaltsverzeichnis

    Contents CONTENTS Page Section 1: INTRODUCTION AND DESCRIPTION Section 2: INSTALLATION Section 3: CONFIGURING THE SYSTEM Section 4: TROUBLESHOOTING Section 5: TECHNICAL SPECIFICATION Section 6: OPERATION Section 7: ADDITIONAL NOTES...
  • Seite 4: Introduction And Description

    Introduction and Description 1 INTRODUCTION This manual is designed to enable you to install your MusiQ system, to configure it to meet your particular needs and to use the system as required. 1.1 OVERVIEW MusiQ enables you to expand your Hi-Fi system into other areas of your home or commercial premises, and to control two of its sources remotely.
  • Seite 5 The RFS version is particularly suited as a retro-fit in domestic installations where speaker wires are already in place or can be easily routed. It can also be used for commercial applications requiring more flexible control. The MusiQ RFS System includes Controller and two Docking RF Handsets.
  • Seite 6: System Features

    Introduction and Description, Installation 1.3 SYSTEM FEATURES Note: The following features are common to all MusiQ variants. • Two Stereo Source inputs - These inputs will normally be from a Tuner and CD player. They can, however, be connected to any source which provides a line level output between 500 mV and 2.0 V rms. •...
  • Seite 7: Installation

    Installation When using an integrated Hi-Fi system without individual source outputs, the recommended connection is to the “Line Out” sockets. These sockets are provided on many systems and may be labelled as “Aux Out” or “Tape out”. Most Mini & Micro systems route the currently selected source to these sockets, this enables MusiQ to distribute the sound from the main system into other areas with independent volume control.
  • Seite 8: General Information

    Installation 2.5 GENERAL INFORMATION 2.5.1 COMPONENT LOCATION Locate MusiQ near to the components that you wish to connect. Ensure that adequate ventilation is allowed around the MusiQ case as this can become warm under use. When installing the MusiQ RFS ensure that both the unit and docking handset (if located on a wall) are positioned away from large metal objects such as filing cabinets.
  • Seite 9: Speaker Connections

    Installation 2.5.4 SPEAKER CONNECTIONS Note: The recommended speaker impedance for use with MusiQ is 8 ohms. The minimum impedance for use with MusiQ is 4 ohms. Use the supplied quick-fit terminals for all speaker cable connections. Strip back each conductor's outer insulation by 6mm, insert bare wire into quick fit plug and secure using the screw terminal fixing.
  • Seite 10 Installation 2.5.5 FITTING KMM MODULE INTO BACK BOX AND WALL PLATES. 1) Clip module into grey mounting frame, as shown. 2) Make all necessary wire connections to module. 3) Screw in to wall box. 4) Clip on System 45* facia plate. *System 45 and Sistema 45 are trade marks of Hamilton Ltd.
  • Seite 11 Installation 2.5.6 KMM KEYPAD/SENSOR CONNECTIONS When using KMM Keypad/Sensors, route a three core cable (telephone cable is ideal for this purpose) from each remote Zone to the rear of the MusiQ and connect as follows (see diagram below). Note: The 6-way connector plug that locates into the Keypad socket at the rear of the MusiQ is inserted UPSIDE DOWN (Screws facing downwards).
  • Seite 12 Installation 2.5.7 RF HANDSET DOCKING PORT To use the infra-red relay feature of the RF handset, route a three core cable (telephone cable is ideal for this purpose) from each docking port to one of the Keypad sockets at the rear of the MusiQ. Connect as follows: ROOM ONE 1 2 3...
  • Seite 13: Connecting A Microphone

    Installation DOCKING PORT TERMINAL NUMBERING 1) Place the Docking Station back plate into the desired location and mark the hole positions. 2) Using a 5mm masonry drill bit, drill two holes 35mm deep at the marked positions. 3) Insert the rawl plugs flush to the wall surface. 4) Wire the connector as detailed in the above diagram.
  • Seite 14: Configuring The System

    Installation, Configuring the System 2.7 FITTING WINDOW EMITTERS In order for the MusiQ to control the source equipment, either by the embedded functions or the I.R. Relay, Window Emitters must be fitted. Each Window Emitter has a lead approximately 1.5m long and is fitted into MusiQ by means of a 3.5mm Jack Plug.
  • Seite 15 Configuring the System 3.1.1 SWITCH 1 - PAGING INHIBIT When using MusiQ with a microphone, you may only want the announcement to be broadcast over one zone. By setting the switch to ON, only Zone A will relay microphone announcements. 3.1.2 SWITCHES 2 AND 3 - ACTIVE EQ SOUND ENHANCEMENT When using very small speaker systems or low cost ceiling speakers you should set the Active EQ sound enhancement feature ON in the appropriate Zone/s to give a fuller and more powerful sound.
  • Seite 16 Configuring the System 3.2 CONFIGURING MULTIPLE MUSIQ RFS When using the RFS version of MusiQ it is important that the address switches of both the MusiQ and RF handsets are set to the same settings. When using more than one MusiQ RFS, it is advisable to set each MusiQ to a different address. The factory defaults will enable the use of one MusiQ RFS without the need to change the address switch settings on the MusiQ or RF Handsets.
  • Seite 17: Troubleshooting

    Troubleshooting 4 TROUBLESHOOTING If you are having problems with the installation DON’T PANIC. It does not necessarily mean that the equipment is faulty. Please follow the following chart to help you diagnose faults and remedy them quickly. PROBLEM SOLUTION IS THE UNIT Connect the mains cable and ensure that both the mains switch on CONNECTED TO THE the front of the MusiQ and at the wall socket are ON.
  • Seite 18: Technical Specification

    Technical Specification, Operation 5 TECHNICAL SPECIFICATION Power Output into 5 Ohms @ 1 kHz 22 W at 0.1%THD One channel driven. Power Output into 5 Ohms @ 1 kHz 20 W at 1.0%THD Two channels driven. Recommended Speaker Impedance: 4 - 16 Ohms Frequency Response: 20 Hz to 20 kHz ±0.5dB Frequency Response of...
  • Seite 19: Operation

    Operation 6.1.1 ENTERING PARTY MODE In normal operation both zones operate independently. Whether you are using a single MusiQ or multiple MusiQs it is sometimes desirable to have all zones selected to the same source, listening at the same volume level. To enter this mode of operation, if using a MusiQ RFS, ensure that both zones are in standby and press both Standby buttons (Zone A &...
  • Seite 20 Operation 6.3 USING A PROGRAMMABLE REMOTE CONTROL WITH KMM MODULES It is possible to teach high quality learning handsets the 10 control commands. These commands are: ‘ZONE A’ Commands ‘ZONE A’ Commands Select Source 1 Select Source 1 Select Source 2 Select Source 2 Standby Standby...
  • Seite 21: Key Functions

    Operation 6.4 KEY FUNCTIONS Infra-red receiver window Switches zone off Press once switches zone on and selects Tuner (Source 1) Press and hold down will skip radio stations (8 stations loop) Press and hold down for 3 seconds, will switchzone on and send play command* to C.D.player (Source 2) Press and hold down for 1.5 seconds will skip to next track...
  • Seite 22: Additional Notes

    Additional Notes 6.5 STATUS DISPLAY RFS CONTROLLER ONLY 1) Microphone Paging Active 2) Zone in Standby Mode 3) Volume Level Indicator 4) Indicates Source Selected 5) Indicates a Command is being received from a KMM or RF Handset 6) Party Mode Activated 7) Serial Data Connection Active.
  • Seite 23 MusiQ Mode d’emploi...
  • Seite 24 “ M a k i n g H i - F i g o p l a c e s ” “ L a H i - F i e n t o u s l i e u x ” “...
  • Seite 25: Certificat De Conformité

    à tout dommage. Si le câble présente des signes d'usure ou de détérioration, ne l'utilisez plus. Demandez à un service technique qualifié ou au service technique QED un cordon de remplacement. Si la MusiQ présente des signes de mauvais fonctionnement, si elle est tombée ou si elle a été endommagée de quelque manière que ce soit, déconnectez immédiatement le cordon secteur de la prise murale.
  • Seite 26 Contenu TABLE DES MATIERES Page Section 1: INTRODUCTION ET DESCRIPTION Section 2: INSTALLATION Section 3: CONFIGURATION DE L'INSTALLATION Section 4: PROBLEMES DE FONCTIONNEMENT Section 5: SPECIFICATIONS TECHNIQUES Section 6: FONCTIONNEMENT Section 7: NOTES ADDITIONNELLES...
  • Seite 27: Introduction Et Description

    Introduction et Description 1 INTRODUCTION Ce manuel est conçu pour vous permettre d'installer votre MusiQ, de la configurer et d'utiliser votre installation selon vos souhaits. 1.1 GÉNÉRALITÉS La MusiQ vous permet de profiter de votre installation Hi-Fi dans les autres chambres de votre habitation ou dans des locaux à...
  • Seite 28 Introduction et Description MusiQ RFS - La face avant de ce modèle permet également une commande intégrale à partir d'une commande à distance RF (Radio Fréquence). Si cette même commande à distance est montée dans un support mural permanent (câblé), cette commande sert également de relais infrarouge. Elle fonctionne alors comme un clavier / œilleton relayant les commandes, imposées à...
  • Seite 29: Installation

    Introduction et Description, Installation 1.3 CARACTÉRISTIQUES DU SYSTÈME Note: Les caractéristiques suivantes sont communes à toutes les variantes de la MusiQ. • Entrées pour deux sources stéréo - Ces entrées servent, en principe, à relier un tuner et un CD. Elles peuvent néanmoins traiter toutes les sources disposant d'un niveau de sortie ligne compris entre les 500 mV et les 2.0 V rms.
  • Seite 30 Installation 2.3 CONNEXION D'INSTALLATIONS HI-FI MINI & MICRO Si vous possédez une installation Hi-Fi intégrée dont les sources ne disposent pas de sorties individuelles, il est recommandé d'utiliser les sorties ligne ('Line Out'). Ces sorties se retrouvent sur de nombreuses installations et portent la dénomination 'Aux Out' ou 'Tape Out'.
  • Seite 31: Informations Générales

    Installation 2.5 INFORMATIONS GÉNÉRALES 2.5.1 LOCALISATION DES COMPOSANTS Placez la MusiQ à côté des sources que vous souhaitez raccorder. Assurez-vous que la ventilation autour de la MusiQ soit suffisante car, en fonctionnement, celle-ci dégage de la chaleur. Lors de l'installation d'une MusiQ RF/ RFS, assurez- vous que l'unité...
  • Seite 32: Raccordement Des Enceintes

    Installation 2.5.4 RACCORDEMENT DES ENCEINTES Note: L'impédance recommandée des enceintes pouvant être utilisées avec la MusiQ est de 8 Ohms. L'impédance minimale autorisée est de 4 Ohms. Pour raccorder les câbles d'enceintes, utilisez les connecteurs à fixation rapide fournis avec l'appareil. Dénudez chaque conducteur sur 6mm.
  • Seite 33 Installation 2.5.5 FIXATION DES PLAQUETTES DE FINITION ET DES MODULES KMM DANS LES BLOCHETS MURAUX 1) Insérez le module dans le cadre gris tel que le montre la figure. 2) Effectuez toutes les connexions du module nécessaires. 3) Vissez l'ensemble dans le blochet. 4) Montez la plaquette de finition System 45.
  • Seite 34 Installation 2.5.6 CONNEXIONS DU CLAVIER / ŒILLETON Si vous utilisez des claviers / œilletons, tracez un câble de données de chaque zone vers l'arrière du MusiQ et connectez-le de la façon suivante (voir figure ci-dessous). Note: Le réceptacle à 6 broches: situé à l'arrière de la MusiQ, où vient se loger le connecteur clavier est monté S'EN DESSUS DESSOUS (vis de fixation vers le bas).
  • Seite 35 Installation 2.5.7 STATION DE REMISAGE POUR COMMANDE À DISTANCE RF Pour profiter de la fonction relais infrarouge au travers de la commande à distance RF, tracez un câble à trois conducteurs de la station de remisage vers un des connecteurs pour clavier situé à l'arrière de la MusiQ. Effectuez les connexions de la façon suivante: ENLEVEZ LE CAPOT DE PROTECTION DE LA STATION DE REMISAGE...
  • Seite 36: Raccordement D'un Microphone

    Installation STATION DE REMISAGE NUMEROTATION DU TERMINAL 1) Placez la partie arrière de la station de remisage dans la position souhaitée et marquez les trous de perçage. 2) Utilisez une mèche à brique de 5 mm et forez deux trous de 35 mm de profondeur aux endroits précédemment marqués.
  • Seite 37: Configuration De L'installation

    Installation, Configuration de l’installation 2.7 PLACEMENT DES ÉMETTEURS VOLANTS Pour que la MusiQ puisse contrôler les sources, par les fonctions induites ou par la fonction relais infrarouge, il est nécessaire de raccorder et de positionner les émetteurs volants. Chaque émetteur volant dispose d'un fil de liaison de 1,5 m environ. Il se relie à la MusiQ par une fiche de 3,5 mm. Avant de fixer définitivement les émetteurs volants, contrôlez le fonctionnement correct de ceux-ci.
  • Seite 38 Configuration de l’installation 3.1.1 COMMUTATEUR 1 - SUPPRESSION DE LA FONCTION COMMUNICATION Lorsque vous reliez un microphone à la MusiQ, vous pouvez souhaiter que les annonces faites ne soient transmises que dans une seule zone. En plaçant le commutateur en ON, seul la zone A relaie les annonces micro. 3.1.2 COMMUTATEURS 2 ET 3 - RENFORCEMENT DU SON PAR ÉGALISATION ACTIVE Si vous utilisez des enceintes de faibles dimensions ou des haut-parleurs encastrables de qualité...
  • Seite 39 Configuration de l’installation 3.2 CONFIGURATION DE MUSIQ RFS MULTIPLES Si vous utilisez la version RFS de la MusiQ, il est important que les commutateurs d'adresse des deux MusiQ et des commandes à distance RF soient configurés de la même manière. Si vous utilisez plus d'une MusiQ RFS, il est nécessaire d'attribuer des adresses différentes à...
  • Seite 40 Problemes de fonctionnement 4 PROBLÈMES DE FONCTIONNEMENT Si, lors de l'installation, des problèmes se présentent, NE PANIQUEZ PAS. L'installation n'est pas nécessairement défectueuse. Suivez le synoptique ci-dessous pour effectuer un diagnostic des problèmes et y remédier rapidement. Problème Solution...
  • Seite 41: Specifications Techniques

    Specifications techniques, Fonctionnement 5 SPÉCIFICATIONS TECHNIQUES Puissance de sortie à 5 Ohms @ 1KHz 22 W à 0,1% DHT Un canal en fonction Puissance de sortie à 5 Ohms @ 1KHz 20 W à 0,1% DHT Deux canaux en fonction Réponse en fréquence 20 Hz à...
  • Seite 42: Fonctionnement

    Fonctionnement 6.1.1 COMMUTATION EN MODE SIMULTANÉ (PARTY MODE) En fonctionnement normal, les deux zones fonctionnent indépendamment. Lorsque vous utilisez une seule ou plusieurs MusiQ, il est parfois souhaitable que toutes les zones reproduisent la même source au même niveau d'écoute. Afin d'obtenir ce mode de fonctionnement, assurez-vous que les deux zones des MusiQ RFS, sont en mode d'attente.
  • Seite 43 Fonctionnement 6.3 UTILISATION DE COMMANDES À DISTANCE PROGRAMMABLES AU TRAVERS DE MODULES KMM Les dix commandes de contrôle peuvent être transférées à une commande à distance programmable de qualité. Ces commandes sont les suivantes: Note: Les commandes à distance infrarouge suivantes ont été testées et fonctionnent parfaitement: Marantz: RC-2000 Marantz: RC-5000 (et Philips Pronto également) ARCAM CR-9000...
  • Seite 44 Fonctionnement 6.4 UTILISATION DES TOUCHES DU CLAVIER Note importante: Ces fonctions ne sont disponibles que si vous utilisez des appareils compatibles, repris dans la liste des marques concernées (voir les spécifications pour connaître les marques concernées). La fonction relais infrarouge de la station de remisage ne peut se faire que si la commande à...
  • Seite 45: Notes Additionnelles

    Notes additionnelles 6.5 AFFICHAGE DE MODE DE FONCTIONNEMENT (RFS UNIQUEMENT) 1) Fonction communication micro activée 2) Zone en mode d’attente 3) Indication du niveau de volume 4) Mentionne la source choisie 5) Mentionne si une commande à partir d’un KMM ou de la commande à distance RF a été...
  • Seite 46 MusiQ Bedienungsanleitung...
  • Seite 47 KONFORMITÄTSERKLÄRUNG, SICHERHEITSHINWEISE KONFORMITÄTSERKLÄRUNG, SICHERHEITSHINWEISE Alle MusiQ Modelle wurden auf die Einhaltung der nachfolgenden Standards entwickelt und von unabhängiger Seite getestet. Sicherheit: EN60065:1993/IEC65, EMC EN55013:1990, EN50082 1:1997, EN61000 3 2:1995, EN61000 3 3:1995. Dieses Symbol erinnert den Benutzer an die Lektüre Dieses Symbol signalisiert dem Benutzer die Anwesenheit der beiliegenden Gebrauchsanleitung.
  • Seite 48 INHALTSVERZEICHNIS CONTENTS Seite Abschnitt 1: PRODUKTBESCHREIBUNG Abschnitt 2: INSTALLATION Abschnitt 3: KONFIGURATION VOM GERÄT Abschnitt 4: FEHLERSUCHE Abschnitt 5: TECHNISCHE SPEZIFIKATIONEN Abschnitt 6: BEDIENUNG Abschnitt 7: ZUSÄTZLICHE NOTIZEN...
  • Seite 49: Einleitung

    PRODUKTBESCHREIBUNG 1 EINLEITUNG Diese Beschreibung wurde erstellt um Ihnen die einfache Installation, die Anpassung des Gerätes auf Ihre Wünsche und den leichten Gebrauch des Gerätes zu ermöglichen. 1.1 ÜBERSICHT Mit jedem MusiQ Gerät kann die Wiedergabe eines beliebigen Hi-Fi Gerätes um zwei zusätzliche Wohn- oder Geschäftsräume erweitert werden.
  • Seite 50 PRODUKTBESCHREIBUNG MusiQ RFS - Dieses Modell beinhaltet die direkte Frontplattenbedienung und das Display vom CM Modell, sowie die zusätzliche Kontrolle via Funkferbedienung. (Siehe MusiQ CM und MusiQ RF Beschreibung). Das MusiQ RFS Paket enthält zwei RF Handsets mit zwei Wandstationen MusiQ RFS Baustein...
  • Seite 51: Gemeinsame Eigenschaften Aller Musiq Modelle

    PRODUKTBESCHREIBUNG, INSTALLATION 1.3 GEMEINSAME EIGENSCHAFTEN ALLER MUSIQ MODELLE • Zwei Stereo Eingänge - Diese Eingänge sind normalerweise für Tuner und CD Player. Es können aber auch andere Tonquellen angeschlossen werden die einen Ausgangspegel zwischen 500 mV und 2.0 V haben. •...
  • Seite 52: Das Anschliessen An Eine Mini Oder Micro Hi-Fi Anlage

    INSTALLATION 2.3 DAS ANSCHLIESSEN AN EINE MINI ODER MICRO HI-FI ANLAGE Wenn eine Kompaktanlage ohne direkte Ausgänge der einzelnen Tonquellen angeschlossen werden soll, ist deren Tonausgang meistens mit "Line out", "Aux out" oder "Tape out" beschriftet. Die meisten Mini oder Micro Geräte haben solche Ausgänge.
  • Seite 53: Aufstellung Der Verschiedenen Komponenten

    INSTALLATION 2.5.1 AUFSTELLUNG DER VERSCHIEDENEN KOMPONENTEN Das MusiQ Gerät sollte in der Nähe der Komponenten stehen mit denen es verbunden werden soll. Da MusiQ während dem Betrieb warm wird, sollte für eine gute Belüftung rund um MusiQ gesorgt werden. Wenn man MusiQ RF/RFS installiert, sollten beide, die Docking Stationen (die an eine Wand montiert werden) und das MusiQ selbst nicht zu nahe an grossen metallischen Flächen (z.B.
  • Seite 54: Lautsprecheranschluss

    INSTALLATION 2.5.4 LAUTSPRECHERANSCHLUSS Merke: Die empfohlene Lautsprecherimpedanz für MusiQ ist 8 Ohm /Stück (minimum 4 Ohm). Die Lautsprecher werden mit den grünen "quick fit" Steckern angeschlossen. Entferne 6mm Isolation vom Kabel, stecke das abisolierte Ende in den Stecker und schraube dieses Ende fest. Achten Sie auf die Polarität des Kabels, da sonst die Klangqualität besonders im Tieftonbereich beeinträchtigt wird.
  • Seite 55: Einbau Des Infrarot Wandbedienteiles (Kmm Modul)

    INSTALLATION 2.5.5 EINBAU DES INFRAROT WANDBEDIENTEILES (KMM MODUL) 1) Befestige das Modul in dem grauen Rahmen (Siehe Abbildung) 2) Schliesse die Kabel am Modul an. 3) Befestige das Modul in der in die Wand eingelassenen UP-Dose mit 2 Schrauben. 4) Überdecke das Modul mit der dekorativen Frontplatte (System 45* facia plate). *System 45 und Sistema 45 sind eingetragene Markenzeichen der Firma Hamilton Ltd.
  • Seite 56 INSTALLATION 2.5.6 INFRAROT WANDBEDIENELEMENTE (KMM SCHALTER/SENSOR) KABELANSCHLUSS Für den Anschluss eines Infrarot Wandbedienelementes am MusiQ Gerät ist ein 3-poliges Kabel notwendig (Siehe Abbildung). Einstellung des Bedienmoduls: An der Rückseite jedes Infrarot Bedienmoduls sind zwei kleine Zweiweg Schalter angebracht, diese sollten folgendermassen eingestellt werden: Wandbedienelement ist in ZONE A / Raum A = Schalter 1 auf OFF Wandbedienelement ist in ZONE B / Raum B = Schalter 1 auf ON...
  • Seite 57 INSTALLATION 2.5.7 RF HANDSET DOCKING PORT Steckt die Funkfernbedienung auf der Docking Station, können normale IR-Fernbedienungen auf sie gerichtet und deren Befehle über größere Distanzen weitergeleitet werden. Die IR-Befehle gelangen dann über die Verbindungsleitung zum Zentralgerät und können von dort an die IR-Empfänger der Tonquellen oder anderer Geräte weitergeleitet werden.
  • Seite 58: Anschluss Eines Mikrofons

    INSTALLATION DOCKING PORT ANSCHLUßNUMERIERUNG 1) Halte die Station an die gewünschte Wandposition und markiere die beiden Bohrlöcher. 2) Mit einem 5 mm Bohrer bohre zwei 35 mm tiefe Löcher und versehe sie mit einem Dübel. 3) Verkable die Station gemäss Abbildung. 4) Schraube die Station an die Wand.
  • Seite 59: Anbringung Der Window Emitter

    INSTALLATION, KONFIGURATION VOM GERÄT 2.7 ANBRINGUNG DER WINDOW EMITTER Um MusiQ mit allen seinen Bedienmöglichkeiten nutzen zu können, müssen die Window Emitter auf den Infrarot Sensoren der beiden Tonquellen angebracht werden (siehe Abbildung). Jeder Window Emitter besitzt ein ca. 1,5 m langes Kabel, das an der Rückwand von MusiQ mit einem 3,5 mm Stecker angeschlossen wird. Diese kleinen Window Emitter können mit den vorhandenen Klebepunkten aufgeklebt werden.
  • Seite 60: Schalter 4 - Slave Oder Master

    KONFIGURATION VOM GERÄT 3.1.1 SCHALTER 1 - ANSAGE UNTERDRÜCKT Ist Schalter 1 in der ON Position, kann eine Mikrofonansage nur in ZONE A gehört werden. 3.1.2 SCHALTER 2 & 3 - ERWEITETER EQ SOUND Bei kleinen oder billigen Lautsprechern, sollten diese beiden Schalter je nach ZONE in der Position ON stehen. Das Klangbild wird dann voller.
  • Seite 61: Konfiguration Eines Musiq Rfs Gerätes

    KONFIGURATION VOM GERÄT 3.2 KONFIGURATION EINES MUSIQ RFS GERÄTES Es ist sehr wichtig, dass die Schalterstellungen für die Funkadresse an beiden Geräte (MusiQ Gerät und Funkfernbedienung) übereinstimmen. Bei einer Zusammenschaltung von mehreren MusiQ RFS Geräte ist es von Vorteil, wenn jedes MusiQ Gerät anders angesprochen wird (Adresse). Beim Betrieb eines MusiQ Gerätes alleine genügt die Herstellereinstellung.
  • Seite 62: Fehlersuche

    FEHLERSUCHE 4 FEHLERSUCHE Wenn nicht alles auf Anhieb funktioniert, geraten sie nicht in Panik. Eine Fehlfunktion bedeutet noch nicht, daß das Gerät defekt ist. Schauen Sie in Ruhe über die Diagnosetafel und korrigieren Sie ggf. den Fehler in der Installationseinstellung. Problem Lösungsvorschlag...
  • Seite 63: Technische Spezifikationen

    TECHNISCHE SPEZIFIKATIONEN, BEDIENUNG 5 TECHNISCHE ANGABEN Ausgangsleistung an 5 Ohm bei 1 kHz 22W mit >0,1% THD Ein Kanal Ausgangsleistung an 5 Ohm bei 1 kHz 20W mit >0,1% THD Zwei Kanal Empfohlene Lautsprecherimpedanz 4 - 16 Ohm Frequenzbereich 20 Hz bis 20 kHz ± 0,5 dB Frequenzbereich wenn EQ +2,75 dB mit 100 Hz relativ zu 0 dB mit 1 Hz Sound Enhancement aktiv:...
  • Seite 64: Party Modus

    BEDIENUNG 6.1.1 PARTY MODUS Normal arbeiten beide ZONEN unabhängig voneinander. Wenn man aber alle ZONEN mit der gleichen Tonquelle mit gleicher Lautstärke betreiben möchte (ein oder mehrere MusiQ Geräte zusammengeschaltet), geht man folgendermassen vor. Bei MusiQ RFS Geräte müssen beide ZONEN im Standby Mode sein. Drücke beide Standby Knöpfe, bis die rote LED Anzeige auf gelb wechselt.
  • Seite 65 BEDIENUNG 6.3 EINSTELLEN EINER PROGRAMMIERBAREN FERNBEDIENUNG MIT DEM KMM MODUL. Es ist möglich, dass man die obigen 5 Funktionen einer lernbaren IR-Fernbedienung für jede Zone eingeben kann. Beachte: Diese Infrarot Bedienung wurden mit folgenden, lernfähigen Handsets erfolgreich getestet: Marantz RC-2000 Marantz RC-5000 (auch Philips Pronto) ARCAM CR-9000 Vorgehen (Siehe Abbildung)
  • Seite 66 BEDIENUNG 6.4 KEY FUNCTIONS Wichtige Anmerkung: Alle Funktionen sind nur möglich, wenn passende Tonquellen eingesetzt werden. Siehe Seite 16! Die Infrarot Link Funktion funktioniert nur, wenn das Handset in seiner (verdrahteten) Wandstation angebracht ist. Zone “A” Zone “B” Fronplattenbedienung am MusiQ RFS Modell Beide ZONEN können von der Frontplatte aus gesteuert werden.
  • Seite 67: Zusätzliche Notizen

    ZUSÄTZLICHE NOTIZEN 6.5 STATUS ANZEIGE (LCD), NUR BEI RFS 1) Mikrofonansage aktiv. 2) ZONE in Wartefunktion (Standby). 3) graphische Lautstärkeanzeige. 4) numerische Eingangsanzeige (Source). 5) quittiert Befehle vom Wandbedien- element oder vom RF Handset. 6) Party Modus ist aktiv. 7) Serial Data Connection aktiv. Diese Anzeige sieht man, wenn Daten innerhalb mehrerer MusiQ Geräte aus getauscht werden.
  • Seite 68 Unit 16, Woking Business Park, Albert Drive, Woking, Surrey, England GU21 5JY Tel:+44 (0) 1483 747474 Fax:+44 (0) 1483 545600 e-mail:panic@qed.co.uk Internet:http//www.qed.co.uk ALL OTHER COUNTRIES PLEASE CONTACT QED. Pour les autres pays, contactez QED. Alle anderen Länder kontaktieren bitte QED direct. M usiQ...
