TDS 600C Features
Options
Table 2: Options
Option # Label
A1 Universal European
power cord
A2 UK power cord
A3 Australian power cord
A4 North American power
cord
A5 Switzerland power cord
HD Hard disk drive
05 Video trigger
13 RS-232/Centronics Hard-
copy Interface Ports
1G 1 GS/s maximum
1K Scope cart
1M
130,000 record length
4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Tektronix will ship the options shown in Table 2:
Description
220 V, 50 Hz power cord
240 V, 50 Hz power cord
240 V, 50 Hz power cord
240 V, 60 Hz power cord
220 V, 50 Hz power cord
Add a hard disk.
Oscilloscope comes with tools for investigating events that occur when a video signal
generates a horizontal or vertical sync pulse. These tools allow investigation of a range of
NTSC, PAL, SECAM, and high definition TV signals. (Option is not available on the
TDS 794D.)
Add RS-232-C and Centronics interface ports.
(Option applies to TDS 500D only.)
Limit sample rate to 1 GS/s maximum.
(Option applies to TDS 520D, TDS 540D, TDS 724D, and TDS 754D only.)
K420 scope cart. This cart can help transport the oscilloscope around many lab environ-
ments.
Extend record length from 50,000 samples standard as follows:
TDS 520D and TDS 724D: To 250,000 samples on one channel and 130,000 on two
channels
TDS 540D, TDS 580D, TDS 754D, TDS 784D, and TDS 794D: To 500,000 samples on one
channel, 250,000 on two channels, and 130,000 samples on three or four channels
(Option is only available for the models listed above.)
TDS 500D, TDS 600C & TDS 700D Supplement
