TDS 600C Features
Option HD
If your TDS 600C contains the optional hard disk, you can use it to save and
recall waveforms, setups, and hard copies as described in the TDS 500D,
TDS 600B & TDS 700D Digitizing Oscilloscopes User Manual. With this
option, you can also run Java-based application programs.
Iomega Zip Drive Support
The TDS 600C is compatible with Iomega 100 Mbyte Zip drives as described in
the TDS 500D, TDS 600B & TDS 700D Digitizing Oscilloscopes User Manual.
Display Measurement
The TDS 600C can display statistics about a measurement as described in the
Statistics TDS 500D, TDS 600B & TDS 700D Digitizing Oscilloscopes User Manual.
Take Optical
The TDS 600C can take Extinction Ratio, Extinction Percent, Extinction dB, and
Measurements Mean dBm measurements as described in the TDS 500D, TDS 600B &
TDS 700D Digitizing Oscilloscopes User Manual.
External Attenuation
The TDS 600C can set External Attenuation as described in the TDS 500D,
TDS 600B & TDS 700D Digitizing Oscilloscopes User Manual.
Probe Calibration
On the TDS 600C, use the TDS 500D and TDS 700D procedures to calibrate a
probe as described in the TDS 500D, TDS 600B & TDS 700D Digitizing
Oscilloscopes User Manual.
3
TDS 500D, TDS 600C & TDS 700D Supplement
