DISCRETE DIGITAL ZOOM
The sight allows you to quickly increase the basic magnification (please
refer to the "Digital zoom" line in the specifications table) by two times
or four times (8 times in LP; XP models), as well as to return to the basic
magnification. To operate the discrete digital zoom, press successively
the DOWN (5) button.
12
HOT MENU FUNCTIONS
The Hot menu allows change of basic settings (display brightness and
contrast, continuous digital zoom, stadiametric rangefinder, information
on the actual profile and zeroing distance).
Enter the menu with a short press of the М (4) button.
To toggle between the functions below, press successively the M
button.
Brightness – press the UP (3) and DOWN (5) buttons to change
display brightness from 00 to 20.
Contrast – press the UP/ DOWN buttons to change display
contrast from 00 to 20.
Digital zoom - press the UP/ DOWN buttons to change digital
zoom from 1.0x to 4.0x (or 8.0x in LP; XP models). Continuous digital
zoom is in 0.1x increments.
The initial value of the continuous digital zoom is x1.0 if the discrete
digital zoom is not active; x2.0 is discrete digital zoom is 2x; x4.0 is
discrete digital zoom is 4x; x8.0 is discrete digital zoom is 8x.
Notes.
- actual magnification is the product of the basic magnification value and
continuous digital zoom value. For example: the sight's basic
magnification is 2.1х, continuous digital zoom value х1.7. Actual
magnification is 3,6х (2,1*1,7).
- display brightness and contrast settings are saved in the memory when
the unit is turned off.
The stadiametric rangefinder
change distance to an object being ranged (please refer to section 17 for
more details).
11
— press the UP/ DOWN buttons to
- information on the actual profile and zeroing distance, at which
A100
zeroing was done in this profile (for example, profile A, zeroing distance
100m).
Toggle between zeroing distances with the UP (3) and DOWN (5)
buttons.
13
MAIN MENU FUNCTIONS
Enter the main menu with a long press of the М (4) button.
Press the UP (3) and DOWN (5) buttons to toggle between the main
menu options.
Main menu navigation is cyclical: as soon as the last menu option of
the first tab is reached, first menu option of the second tab starts.
Enter a submenu of the main menu with a short press of the М button.
Exit the submenu with a long press of the М button.
Automatic exit takes place in 10 sec of inactivity.
Upon exit from the menu the cursor location
the duration of the working session (i.e. until the unit is turned off).
Upon restarting the sight and entering the menu the cursor will be
located on the first menu option.

MENU CONTENTS:

Tab 1
Menu Wi-Fi activation
Off
Automatic
A
is memorized only for
Tab 2
Menu General settings
Off
Off
+
