9.4 Illuminators

LED SMD
GEKO IRN - BEAM PATTERN AND ACHIEVABLE DISTANCES FOR ONE
ILLUMINATOR
Horizontal Maximum distance
and vertical
850nm
beam pat-
terns
10˚ 240m (787ft)
30˚ 130m (427ft)
60˚ 80m (262ft)
Tab. 4
The distances and the performance depend on the
camera/lens used and on the environmental light
conditions.
1 Achievable distances with camera in Day mode
(colour image)

9.5 Environment

For installation indoors and outdoors
Operating temperature: From -40°C (-40°F) up to
+60°C (140°F)
12
940nm White light
140m (460ft) –
80m (262ft) 120m (393ft)1
60m (197ft) 90m (295ft)1

9.6 Certifications

Electrical safety (CE): EN60950-1, IEC60950-1
Electromagnetic compatibility (CE): EN50130-4, IEC
CISPR22 (Class A) , EN55022 (Class A), FCC Part 15
(Class A)
Outdoor installation (CE): EN60950-22, IEC60950-22
Photobiological safety (CE): EN62471
IP protection degree (EN60529):
• IP66
• IP67
IK protection degree (EN62262):
• IK10
UL certification: cULus Listed (TYPE 4X)
EAC certification
MNVCIRN_1828_EN
