7.3 Operational test

7.3.1 Check operation of the twilight
sensor
Check operation of the twilight sensor by darkening
it with black tape.
8 Information on disposal
and recycling
The European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE) mandates
that these devices should not be disposed of in the
normal flow of municipal solid waste, but they should
be collected separately in order to optimize the
recovery stream and recycling of the materials that
they contain and to reduce the impact on human
health and the environment due to the presence of
potentially hazardous substances.
The symbol of the crossed out bin is marked
on all products to remember this.
The waste may be delivered to appropriate collection
centers, or may be delivered free of charge to the
distributor where you purchased the equipment at
the time of purchase of a new equivalent or without
obligation to a new purchase for equipment with size
smaller than 25cm (9.8in).
For more information on proper disposal of these
devices, you can contact the responsible public
service.
MNVCIRN_1828_EN

9 Technical data

9.1 General

Supplied complete with support
Adjustable built-in twilight sensor for automatic
activation and deactivation

9.2 Mechanical

Die cast aluminum body
Dimensions: 187x251x242mm (7.4x9.9x9.5in)
Unit weight:
• 1.7kg (3.7lb) (from 12Vdc up to 24Vdc, 24Vac)
• 2.2kg (4.8lb) (from 100Vac up to 240Vac)

9.3 Electrical

Supply voltage/Current consumption:
• From 12Vdc up to 24Vdc, 2.5A max
• 24Vac, 2.5A max, 50/60Hz
• From 100Vac up to 240Vac, 1.5A max, 50/60Hz
Power supply voltages permitted tolerance:
• From 100Vac up to 240Vac: ±10%
• 24Vac or 24Vdc: ±10%
• 12Vdc: ±5%
Input for activation by means of external dry contact
Dry contact output (Follow)
Multipolar cable L: 2m (6.56ft)
• Control: 4x0.34mm² (22AWG)
• Power supply from 12Vdc up to 24Vdc, 24Vac: 2x0
.75mm² (18AWG)
• Power supply from 100Vac up to 240Vac: 3x0.75
mm² (18AWG)
