1. INTRODUCTION

This manual was created to help you install and learn all about the functional possibilities of the NCL scale.
The scales should be sited in a location that will not degrade the accuracy.
Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents.
Avoid unsuitable tables. The tables or floor must be rigid and not vibrate. Do not place near vibrating machinery.
Avoid unstable power sources. Do not use near large users of electricity such as welding equipment or large motors.
Avoid high humidity that might cause condensation. Avoid direct contact with water. Do not spray or immerse the scales in
water.
Avoid air movement such as from fans or opening doors. Do not place near open windows.
Keep the scales clean.
Do not stack material on the scales when they are not in use.

2. MAIN TECHNICAL SPECIFICATIONS

Model
(dimensions in mm)
NCL3K 235 x 335
NCL6K 235 x 335
NCL15K 235 x 335
NCL30K 235 x 335
Operative Temperature:
Relative humidity:
Power supply:
Zero range:
Auto zero at start-up:
Plate Capacity kg
0°C - 40°C / 32°F - 104°F.
≤ 85 % RH
AC 240V (±10%) / 50 Hz, 110V/60HZ
DC 4V / 4Ah with rechargeable accumulator inside.
+/- 2% of max load capacity.
+/- 10% of max load capacity.
WARNINGS
Division g
3 0,1
6 0,2
15 0,5
30 1,0
4
Resolution g CE-M Division g
0,01
0,02
0,05
0,10
1
2
5
10
