6.4 GRAVITY OF CALIBRATION AND USE ZONES

a) Keep pressed the TARE key for about 4 seconds: the "Average Piece Weight" display will show "CAL_G", and the
"weight" display will show the gravity value of the calibration zone
b) Modify the value trough the numeric keyboard and confirm by pressing M+.
c) The "unit weight" display will show "USE_G", and the "weight" display will show the gravity value of the use zone
d) Modify the value trough the numeric keyboard and confirm by pressing M+.
e) Once the value is confirmed the scale return in weighing mode.

6.5 WEIGHING FILTER

1. Press both the PCS and 5 keys during normal weighing.
2. By pressing the TARE key one selects the available filter: SPd 0, SPd 1, SPd 2, SPd 3, SPd 4. The higher the
filter value, and greater is its intervention.
3. Confirm with M+.

6.6 DISPLAY BACKLIGHT

By keeping pressed the ZERO-B.L. key, the display will scroll the possible activation modes; release the key when the
desired functioning is displayed:
OFF backlighting always off
ON backlighting always on.
AUTO backlighting on when the weight is unstable or when a key is pressed. The backlighting remains active for 5
seconds.

7. MESSAGES

MESSAGES
- - OF - -
Err 2 / ZERO
UNSTA
- - ADC - -
- SYS -
- LO -
- - AC - -

RECYCLING INSTRUCTION

The crossed-out wheeled bin on the product means that at the product end of life, it
must be taken to separate collection or to the reseller when a new equivalent type of
equipment is purchased. The adequate differentiated refuse collection in having the
product recycled, helps to avoid possible negative effects on the environment and
health and supports the recycling of the materials of which the equipment is made.
The unlawful disposal of the product by the user will entail fines foreseen by the
current regulations.
DESCRIPTION RESOLUTION
Over range Remove weight from the scale.
Zero Error Upon start-up or when the ZERO key is pressed, the weight on the
scale exceeds the +/- 10% of the max. capacity.
Remove the excess weight and retry.
Auto Zero Error Upon start-up, the weight on the scale is not stable to be zeroed. It
maybe because of the platform's intensity is too low or the platform is
shaken strongly.
You may strengthen the platform or avoid the shake.
Input signal Indicates that the A/D converter value is overflows:
overflow error - Remove the weight from the scale if it's exceeding.
- The load cell or the electronics could be damaged.
Calibration error Please re-calibrate the scale with the procedure with zero acquisition
(see section 6.3). If the problem persists contact the dealer.
Accumulator One can use the scale in a short time, but you should plug in the AC
voltage low plug as soon as possible to recharge the accumulator.
Accumulator
recharge.
