Spare parts list:

PILOT Premium
Gravity-Feed Cup
V 10 701
Item Designation Qty. Item number
1 Air head nut compl. 1 V 20 700 05 000
2 Air head 1 V 10 700 35 XXX*
3 Material nozzle 1 V 10 700 40 XX3*
5 Air distributor ring 1 V 10 701 14 000
6 Gun body with bushings 1 V 10 701 01 000
7 Needle seal compl. 1 V 09 001 72 000 ♦
8 Packing screw 1 V 10 701 02 000
9 Material needle 1 V 10 701 30 XX3*
10 Driving bushing 1 V 10 306 06 000
11 Counter screw 1 V 10 701 03 000
12 Needle spring 1 V 10 701 40 000
13 Spring cap 1 V 10 701 04 000
14 Sealing cone 1 V 11 700 11 200
15 Lock washer 1 V 10 151 23 000
16 Guide bushing 1 V 10 600 05 200
17 Packing 1 V 09 101 02 020 ♦
18 Packing screw 1 V 10 600 29 100
19 Regulating screw 1 V 10 701 06 000
20 Valve packing gland 1 V 10 701 07 000
21 Valve shaft seal 1 V 11 750 20 000
22 O-ring 1 V 09 102 38 001 ♦
23 Valve shaft compl. 1 V 10 701 08 300
24 Valve cone 1 V 10 701 08 000
25 Valve spring 1 V 10 701 41 000
26 Cap screw 1 V 11 700 27 400
27 Bushing, air volume reg. 1 V 10 701 05 000
28 Seal, air volume reg. 1 V 10 701 09 000 ♦
29 Air volume regulation 1 V 10 701 10 000
30 Lever screw 1 V 10 301 09 000
31 Trigger 1 V 10 701 11 000
32 Lever shank screw 1 V 10 600 20 100
33 Limiting pin 1 V 10 701 12 000
34 Colour ring
35 Double nipple 1 V 00 101 01 000
36 Cup compl. 1 V 00 130 00 060
37 Double nipple
39 Spring washer 1 V 10 701 11 100
PILOT Premium PILOT Premium
HVLP
Material connection Gravity-Feed Cup
V 10 702 V 10 703
Qty. Item number Qty. Item number
1 V 20 700 05 000 1 V 20 700 05 000
1 V 10 700 35 XXX* 1 V 10 700 36 XXX*
1 V 10 700 40 XX3* 1 V 10 700 40 XX3*
1 V 10 701 14 000 1 V 10 701 14 100
1 V 10 702 01 000 1 V 10 703 01 000
1 V 09 001 72 000 ♦ 1 V 09 001 72 000 ♦
1 V 10 702 02 000 1 V 10 701 02 000
1 V 10 702 30 XX3* 1 V 10 701 30 XX3*
1 V 10 306 06 000 1 V 10 306 06 000
1 V 10 701 03 000 1 V 10 701 03 000
1 V 10 701 40 000 1 V 10 701 40 000
1 V 10 701 04 000 1 V 10 701 04 000
1 V 11 700 11 200 1 V 11 700 11 200
1 V 10 151 23 000 1 V 10 151 23 000
1 V 10 600 05 200 1 V 10 600 05 200
1 V 09 101 02 020 ♦ 1 V 09 101 02 020 ♦
1 V 10 600 29 100 1 V 10 600 29 100
1 V 10 702 06 000 1 V 10 701 06 000
1 V 10 701 07 000 1 V 10 701 07 000
1 V 11 750 20 000 1 V 11 750 20 000
1 V 09 102 38 001 ♦ 1 V 09 102 38 001 ♦
1 V 10 701 08 300 1 V 10 701 08 300
1 V 10 701 08 000 1 V 10 701 08 000
1 V 10 701 41 000 1 V 10 701 41 000
1 V 11 700 27 400 1 V 11 700 27 400
1 V 10 701 05 000 1 V 10 701 05 000
1 V 10 701 09 000 ♦ 1 V 10 701 09 000 ♦
1 V 10 701 10 000 1 V 10 701 10 000
1 V 10 301 09 000 1 V 10 301 09 000
1 V 10 701 11 000 1 V 10 701 11 000
1 V 10 600 20 100 1 V 10 600 20 100
1 V 10 701 12 000 1 V 10 701 12 000
1 V 10 701 13 200
1 V 00 101 01 000 1 V 00 101 01 000
1 V 00 130 00 060
1 V 00 101 04 pre
1 V 10 701 11 100 1 V 10 701 11 100
26
Spare parts list:
PLUS
Item Designation
1 Air head nut compl.
2 Air head
3 Material nozzle
5 Air distributor ring
6 Gun body with bushings
7 Needle seal compl.
8 Packing screw
9 Material needle
10 Driving bushing
11 Counter screw
12 Needle spring
13 Spring cap
14 Sealing cone
15 Lock washer
16 Guide bushing
17 Packing
18 Packing screw
19 Regulating screw
20 Valve packing gland
21 Valve shaft seal
22 O-ring
23 Valve shaft compl.
24 Valve cone
25 Valve spring
26 Cap screw
27 Bushing, air volume reg.
28 Seal, air volume reg.
29 Air volume regulation
30 Lever screw
31 Trigger
32 Lever shank screw
33 Limiting pin
34 Colour ring
35 Double nipple
36 Cup compl.
37 Double nipple
39 Spring washer
PILOT Premium PILOT Premium HVLP
HVLP
PLUS
Material connection Gravity-Feed Cup
V 10 704 V 10 705
Qty. Item number Qty. Item number
1 V 20 700 05 000 1 V 20 700 05 000
1 V 10 700 36 XXX* 1 V 10 700 37 XXX*
1 V 10 700 40 XX3* 1 V 10 700 40 XX3*
1 V 10 701 14 100 1 V 10 701 14 100
1 V 10 704 01 000 1 V 10 705 01 000
1 V 09 001 72 000 ♦ 1 V 09 001 72 000 ♦
1 V 10 702 02 000 1 V 10 701 02 000
1 V 10 702 30 XX3* 1 V 10 701 30 XX3*
1 V 10 306 06 000 1 V 10 306 06 000
1 V 10 701 03 000 1 V 10 701 03 000
1 V 10 701 40 000 1 V 10 701 40 000
1 V 10 701 04 000 1 V 10 701 04 000
1 V 11 700 11 200 1 V 11 700 11 200
1 V 10 151 23 000 1 V 10 151 23 000
1 V 10 600 05 200 1 V 10 600 05 200
1 V 09 101 02 020 ♦ 1 V 09 101 02 020 ♦
1 V 10 600 29 100 1 V 10 600 29 100
1 V 10 702 06 000 1 V 10 701 06 000
1 V 10 701 07 000 1 V 10 701 07 000
1 V 11 750 20 000 1 V 11 750 20 000
1 V 09 102 38 001 ♦ 1 V 09 102 38 001 ♦
1 V 10 701 08 300 1 V 10 701 08 300
1 V 10 701 08 000 1 V 10 701 08 000
1 V 10 701 41 000 1 V 10 701 41 000
1 V 11 700 27 400 1 V 11 700 27 400
1 V 10 701 05 000 1 V 10 701 05 000
1 V 10 701 09 000 ♦ 1 V 10 701 09 000 ♦
1 V 10 701 10 000 1 V 10 701 10 000
1 V 10 301 09 000 1 V 10 301 09 000
1 V 10 701 11 000 1 V 10 701 11 000
1 V 10 600 20 100 1 V 10 600 20 100
1 V 10 701 12 000 1 V 10 701 12 000
1 V 10 701 13 200 1 V 10 701 13 300
1 V 00 101 01 000 1 V 00 101 01 000
1 V 00 130 00 060
1 V 00 101 04 pre
1 V 10 701 11 100 1 V 10 701 11 100
27
PILOT Premium HVLP
Material connection
V 10 706
Qty. Item number
1 V 20 700 05 000
1 V 10 700 37 XXX*
1 V 10 700 40 XX3*
1 V 10 701 14 100
1 V 10 706 01 000
1 V 09 001 72 000 ♦
1 V 10 702 02 000
1 V 10 702 30 XX3*
1 V 10 306 06 000
1 V 10 701 03 000
1 V 10 701 40 000
1 V 10 701 04 000
1 V 11 700 11 200
1 V 10 151 23 000
1 V 10 600 05 200
1 V 09 101 02 020 ♦
1 V 10 600 29 100
1 V 10 702 06 000
1 V 10 701 07 000
1 V 11 750 20 000
1 V 09 102 38 001 ♦
1 V 10 701 08 300
1 V 10 701 08 000
1 V 10 701 41 000
1 V 11 700 27 400
1 V 10 701 05 000
1 V 10 701 09 000 ♦
1 V 10 701 10 000
1 V 10 301 09 000
1 V 10 701 11 000
1 V 10 600 20 100
1 V 10 701 12 000
1 V 10 701 13 300
1 V 00 101 01 000
1 V 00 101 04 pre
1 V 10 701 11 100
