EN
STEP 3
Place the armrest and control panel section onto the upper aluminium column aligning the holes in
both sections.
Fix the armrest and control panel in place using the M6 x 70mm lock nut.
STEP 4
Extend the upper aluminium column and secure in position using 2 x M6 x 40mm lock nuts and
plastic gaskets.
49
