ENGLISH (Original instructions)
1-1. Hole diameter 8 mm
2-1. 6 mm Std. washer
2-2. No.10 wood screw 40 mm min.
length
3-1. 6 mm Std. washer
3-2. 6 mm Mounting bolt & Nut tighten
securely
4-1. Push stick
5-1. Rip fence (Guide rule)
5-2. Miter gauge
6-1. Handle
7-1. Arrow pointer
7-2. Lock lever
8-1. 90 ﾟ adjusting screw
8-2. 45 ﾟ adjusting screw
10-1. Arrow pointer
11-1. Switch
11-2. Restart button
12-1. Screws
13-1. Sub table (R)
14-1. Screws
14-2. Sub table (back)
15-1. Slide table
15-2. Locking plate
16-1. Wrench
16-2. Wrench

SPECIFICATIONS

Model
Arbor hole
Blade diameter
Max. cutting capacities
No load speed (min
Table size (L x W)
Dimensions (L x W x H) with table(s) not extended
Net weight
Safety class
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･
Read instruction manual.
･

DOUBLE INSULATION

Explanation of general view
16-3. Hex nut
17-1. Inner flange
17-2. Ring
17-3. Saw blade
17-4. Outer flange
17-5. Hex nut
18-1. Wrench
18-2. Wrench
19-1. Blade guard
19-2. Riving knife
19-3. Blade guard mounting portion
(stay)
20-1. Blade guard
20-2. Riving knife
21-1. Blade guard
21-2. Riving knife
22-1. Blade guard
22-2. Riving knife
23-1. Blade
23-2. These two clearances should be
equal.
23-3. Blade guard mounting portion
(stay)
23-4. Riving knife
23-5. Hex bolts (A)
23-6. Hex bolts (B)
90°
45°
-1
)
(685 mm - 835 mm) x (955 mm - 1,305 mm)
with sub tables (R) and (back)
726 mm x 984 mm x 333 mm
with sub tables (R) and (back)
END215-3
(for European countries)
30 mm
260 mm
93 mm
64 mm
34.1 kg
･
･
5
24-1. Blade guard
24-2. Riving knife
25-1. Lever
26-1. Scale
27-1. Hex bolts
29-1. Guideline
29-2. Screw
31-1. Face/edge parallel
31-2. Handle
31-3. Wood screw
31-4. Glue together
32-1. Face/edge parallel
35-1. Push stick
36-1. Auxiliary fence
37-1. Push block
37-2. Auxiliary fence
38-1. Cross cutting
38-2. Mitering
38-3. Bevel cutting
38-4. Compound mitering (angles)
39-1. Miter gauge
39-2. Knob
43-1. Brush holder cap
43-2. Screwdriver
MLT100
(for other than European countries)
25 mm and 25.4 mm
255 mm
90.5 mm
63 mm
4,300
(685 mm - 835 mm) x (955 mm - 1,305 mm)
with sub tables (R) and (back)
726 mm x 984 mm x 333 mm
with sub tables (R) and (back)
34.1 kg
./II
Wear safety glasses.
Do not place hand or fingers close to
the blade.
