Mains connection (V):
~(Hz):
Welding current (A):
GB
Electrodes (Ø mm):
Idling voltage (V):
Power input (kW):
Fuse (A):
Weight (kg):
5. CABLE CONNECTION TO THE MAINS
SOCKET
Among three-core cables, two shall be the input power
cables and one double-color (yellow-green) shall be
the earthing wire with PE bushing. See
lines.
Using surge protector is recommended to protect the
machine from the À uctuation of voltage.
6. WELDING PREPARATIONS
Connect the earth terminal
welded or to the support on which the part is resting.
Ensure that the earth terminal is in direct contact with
the part to be welded. You should therefore avoid coat-
ed surfaces and/or insulated materials. The electrode
holder cable has a special clamp at one end, which is
used to secure the electrode. The welding safety shield
must be used at all times for welding. It protects your
eyes from the radiation emitted by the arc and never-
theless enables you to watch the welding process.
7. WELDING
After you have made all the electrical connections for
the power supply and for the welding circuit, you can
proceed as follows:
Insert the unsheathed end of the electrode into the
electrode holder
to the part you wish to weld.
Ensure that a good electric contact is made. Switch on
the welding set at the switch
current using the hand wheel
you wish to use. Hold the safety shield in front of your
face and rub the tip of the electrode on the part you
wish to weld as if you were striking a match. This is
the best method of igniting the arc. Check that you
have the correct electrode and current strength on a
test part.
8
230
50
55-160
2-4
48
6,4
22
12,6
2
for guide-
direct to the part to be
and connect the earth terminal
and set the welding
to suit the electrode
Electrode (Ø mm)
2
2,5
3,2
4
Important!
Do not dab the workpiece with the electrode
since it could be damaged, making it more
dif¿ cult to ignite the arc.
As soon as the arc has ignited, attempt to keep it a
distance from the workpiece equivalent to the diameter
of the electrode.
This distance should be kept as constant as possible
during the welding process. The angle of the electrode
in the direction in which you are working should be
20/30°.
Important!
Always use tongs to remove spent electrodes
and to
move parts that you have just welded. Please note that
the electrode holder
must always be put down so
that it is insulated after you have completed the weld-
ing work.
Do not remove the slag until the weld has cooled. If you
want to continue a weld after an interruption, the slag
from your initial attempt must ¿ rst be removed.
Switch off and unplug the machine after operation.
8. OVERHEATING GUARD
The welding set is ¿ tted with an overheating guard that
protects the welding transformer from overheating. If
the overheating guard trips, the control lamp
your set will be lit. Allow the welding set to cool for a
time.
9. MAINTENANCE
Switch off and unplug the machine before carrying out
any maintenance works on it. Remove dust and dirt
from the machine at regular intervals. Cleaning is best
carried out with a ¿ ne brush or a cloth.
Welding current (A)
40-80 A
60-110A
80-160 A
120-200 A
on
